Technical Specifications
Specification Summary
| Form Factor | ATX (30.5cm × 24.4cm) |
| Operating System Support | Windows 11 64-bit |
Processor (CPU)
| Supported CPUs | AMD Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors |
| Note | Refer to GIGABYTE’s website for the latest CPU support list. |
Chipset
| Chipset Model | AMD X870 |
Memory
| Slots | 4 × DIMM |
| Capacity | Up to 256 GB (64 GB per DIMM) |
| Architecture | Dual Channel |
| Speed Support (MT/s) | 8200(OC), 8000(OC), 7800(OC), 7600(OC), 7200(OC), 7000(OC), 6800(OC), 6666(OC), 6600(OC), 6400(OC), 6200(OC), 6000(OC), 5600(OC), 5200, 4800, 4400 |
| Module Type | Non-ECC Un-buffered DIMM 1Rx8 / 2Rx8 / 1Rx16 |
| Profiles Supported | AMD EXPO™, Intel XMP |
| Note | Supported memory type and speed vary depending on CPU and configuration. |
Onboard Graphics
| USB4 Controller | ASMedia USB4® Controller |
| Display Outputs | 2 × USB4 Type-C (DisplayPort 1.4, 3840×2160@240 Hz, HDR) 1 × HDMI 2.1 (4096×2160@60 Hz, HDCP 2.3, HDR) 1 × Front HDMI 1.4 (1920×1080@30 Hz) |
| Multi-Display Support | Up to 4 Displays Simultaneously |
Audio
| Chipset | Realtek® ALC1220 CODEC |
| Channels | 2 / 4 / 5.1 / 7.1 HD Audio |
| Features | DSD Audio (Line Out) • S/PDIF Out • Configurable Audio Jacks via Software |
Networking
| LAN | LAN |
| Wireless (rev.1.0) | MediaTek Wi-Fi 7 MT7925 – Dual-band (2.4/5/6 GHz), BT 5.4, 11be 160MHz |
| Wireless (rev.1.1) | Realtek® Wi-Fi 7 RTL8922AE – Dual-band (2.4/5/6 GHz), BT 5.4, 11be 160MHz |
| Note | Wi-Fi 7 requires Windows 11 SV3; no driver support for Windows 10. Channel support depends on country regulations. |
Expansion Slots
| From CPU | 1 × PCIe x16 (PCIEX16) – PCIe 5.0 x16 (Ryzen 9000/7000) <br> PCIe 4.0 x8 (Ryzen 8000 Phoenix 1) <br> PCIe 4.0 x4 (Ryzen 8000 Phoenix 2) |
| Bandwidth Sharing | PCIEX16 shares bandwidth with M2B_CPU and M2C_CPU (drops to x8 when either populated) |
| From Chipset | 1 × PCIe x16 (PCIEX4) – PCIe 4.0 x4 1 × PCIe x16 (PCIEX2) – PCIe 3.0 x2 |
| Note | PCIEX4 slot disabled when M2D_SB is used. PCIEX16 slot supports GPU or NVMe SSD only. |
Storage Interface
| M.2 Slots | M2A_CPU: PCIe 5.0 / 4.0 x4/x2 (25110 / 22110 / 2580 / 2280) <br> M2B_CPU / M2C_CPU: PCIe 5.0 x4/x2 (22110 / 2280) – Disabled on Ryzen 8000 <br> M2D_SB: PCIe 4.0 x4/x2 (22110 / 2280, from chipset) |
| SATA Ports | 4 × SATA 6 Gb/s |
| NVMe RAID | RAID 0 / 1 / 5 / 10 (RAID 5 only with Ryzen 9000) |
| SATA RAID | RAID 0 / 1 / 10 |
USB Connectivity
| ASMedia Controller | 2 × USB4 Type-C (back panel, DisplayPort 1.4) |
| USB 3.2 Hub | 4 × USB 3.2 Gen 1 (back panel) |
| USB 2.0 Hub | 4 × USB 2.0/1.1 (back panel) |
| Chipset | 1 × USB-C (3.2 Gen 2x2, internal) • 2 × USB-A (3.2 Gen 2, red) • 2 × USB 3.2 Gen 1 (internal) • 4 × USB 2.0 (internal) |
Internal I/O Connectors
| Power Connectors | 24-pin ATX • Dual 8-pin CPU Power |
| Cooling | 1 × CPU Fan • 1 × CPU Pump • 4 × System Fan • 2 × System Pump |
| Lighting | 3 × ARGB Gen 2 • 1 × RGB Header |
| Storage | 4 × M.2 • 4 × SATA 6 Gb/s |
| Front Panel | Power • Reset • Audio • USB-C (3.2 Gen 2x2) • USB 3.2 • USB 2.0 |
| Sensors & Security | 2 × Temp Sensors • TPM 2.0 Header • Noise Detection Header |
| Miscellaneous | Power Button • Reset Button • HDMI Port • Clear CMOS Jumper |
Back Panel Connectors
| Display Outputs | 1 × HDMI 2.1 • 2 × USB4 Type-C (DisplayPort 1.4 support) |
| USB Ports | 2 × USB 3.2 Gen 2 (red) • 4 × USB 3.2 Gen 1 • 4 × USB 2.0 |
| Network | 1 × RJ-45 (2.5GbE) |
| Audio | 2 × Audio Jacks • 1 × Optical S/PDIF Out |
| Wireless | 2 × Antenna Connectors (2T2R) |
| Buttons | Q-Flash Plus Button |
Monitoring & BIOS
| Monitoring | Voltage, Temperature, Fan Speed, Flow Rate, Noise Detection, Fan Fail Warning, Fan Control |
| BIOS | 256 Mbit AMI UEFI BIOS |
| Compliance | PnP 1.0a, DMI 2.7, WfM 2.0, SMBIOS 2.7, ACPI 5.0 |
| Utilities | Q-Flash, Q-Flash Plus, Smart Backup |
Warranty Information
| Duration | 03 Years |
