Technical Specifications
Chipset & CPU Support
| Chipset | AMD B650 |
| CPU Socket | AMD AM5 |
| Supported Processors | AMD Ryzen™ 7000 / Ryzen™ 8000 / Ryzen™ 9000 Series Processors |
| Architecture Support | Zen 4 / Zen 5 |
| CPU Compatibility Note | Refer to GIGABYTE CPU Support List for the latest updates |
Memory
| Memory Type | DDR5 |
| DIMM Slots | 2 x DDR5 DIMM sockets |
| Maximum Capacity | Up to 128 GB (64 GB per DIMM) |
| Channel Architecture | Dual Channel |
| Supported Speeds | DDR5 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MHz |
Integrated Graphics
| Graphics Processor | Integrated AMD Radeon™ Graphics (on supported CPUs) |
| Display Outputs | <ul><li>1 x HDMI 2.1 (Max 4096x2160 @ 60Hz)</li><li>1 x D-Sub (Max 1920x1200 @ 60Hz)</li></ul> |
| Display Features | Supports HDCP 2.3 and native HDMI 2.1 TMDS |
Audio
| Audio Codec | Realtek High Definition Audio CODEC |
| Channels | 2 / 4 / 5.1 / 7.1-channel HD Audio |
| Custom Audio Control | Configurable via Realtek Audio Software |
| Audio Jack Reassignment | Supported through software interface |
Networking
| LAN Controller | Realtek 2.5GbE LAN |
| Speed | 2.5 Gbps / 1 Gbps / 100 Mbps |
| Wireless Module | AzureWave Wi-Fi AW-CB304NF (Realtek® RTL8821CE) |
| Wi-Fi Standard | 802.11 a/b/g/n/ac, Dual Band (2.4GHz & 5GHz) |
Storage
| M.2 Slot | 1 x M.2 (Socket 3, M Key, Type 2580/2280) |
| M.2 Interface | PCIe 4.0 x4/x2 (depends on CPU) |
| SATA Ports | 4 x SATA 6Gb/s |
| RAID Support | RAID 0, RAID 1, RAID 10 for NVMe and SATA |
USB Connectivity
| CPU-based Ports | 2 x USB 3.2 Gen 1 (rear), 1 x USB 2.0 (rear) |
| Chipset-based Ports | 2 x USB 3.2 Gen 1 (internal header), 5 x USB 2.0/1.1 (3 rear + 2 internal) |
| Chipset + Hub | 2 additional USB 2.0 ports (internal header) |
| Total USB Ports | Up to 12 ports total (6 rear + 6 internal) |
Internal I/O Connectors
| Power Connectors | 1 x 24-pin ATX Main, 1 x 8-pin ATX 12V |
| Cooling Headers | 1 x CPU Fan, 2 x System Fan |
| Lighting Headers | 2 x Addressable LED Headers, 1 x RGB LED Header |
Operating System Support
| Supported OS | Windows 11 64-bit, Windows 10 64-bit |
Physical Specifications
| Form Factor | Micro ATX |
| Dimensions | 24.0 cm x 22.5 cm |
| Mounting Standard | mATX Mounting Holes |
Warranty Information
| Warranty | 3 Years |
