Technical Specifications
CPU
| Socket | AMD AM5 |
| Supported CPUs | Ryzen 9000 / 8000 / 7000 |
Chipset
| Chipset | AMD X870 |
Memory
| Type | DDR5 Dual-Channel |
| Slots | 4 × DIMM |
| Max Capacity | 256 GB |
Graphics
| USB4 Display | 2 × USB4 Type-C, DP 3840×2160@240 Hz |
| HDMI Back | HDMI 2.1, 4096×2160@60 Hz |
| HDMI Front | HDMI 1.4, 1920×1080@30 Hz |
| Display Support | Up to quad-display |
Audio
| Codec | Realtek ALC1220 |
| Channels | 2/4/5.1/7.1 |
| S/PDIF Out | Yes |
Storage
| M2A_CPU | PCIe 5.0/4.0 x4/x2, 25110/22110/2580/2280 |
| M2B_CPU | PCIe 5.0 x4/x2, 22110/2280 |
| M2C_CPU | PCIe 5.0 x4/x2, 22110/2280 |
| M2D_SB | PCIe 4.0 x4/x2, 22110/2280 |
| SATA | 4 × SATA 6Gb/s |
USB
| USB4 | 2 × Type-C |
| Rear USB | 4 × USB 3.2 Gen1, 2 × USB 3.2 Gen2 Type-A, 4 × USB 2.0 |
| Internal USB | USB-C Gen2x2, 2 × USB 3.2 Gen1, 4 × USB 2.0 |
Internal Connectors
| Power | 24-pin ATX, 2 × 8-pin ATX12V |
| Cooling | 1 × CPU fan, 1 × CPU/PUMP, 4 × system fan, 2 × fan/PUMP |
| RGB | 3 × ARGB Gen2, 1 × RGB |
| Storage | 4 × M.2, 4 × SATA |
| Front Panel | Power, Reset, Audio |
| USB Headers | USB-C Gen2x2, USB 3.2 Gen1, 2 × USB 2.0 |
| Other | TPM header, Noise detection, Clear CMOS, Reset jumper, Temp sensor ×2 |
Software
| Utilities | GIGABYTE Control Center |
| Security | Norton Internet Security (OEM) |
Operating System
| OS Support | Windows 11 64-bit |
Form Factor
| Size | ATX, 30.5 cm × 24.4 cm |
Warranty Information
| warranty | 03 Years |
