Technical Specifications
Chipset & CPU Support
| Feature | Details |
| Chipset | AMD B650 |
| CPU Socket | AMD AM5 |
| Supported Processors | AMD Ryzen™ 7000 / Ryzen™ 8000 / Ryzen™ 9000 Series Processors |
| Architecture Support | Architecture Support Zen 4 / Zen 5 |
| CPU Support Note | Refer to GIGABYTE’s official CPU support list for compatibility updates |
| Integrated Graphics | Supported on Ryzen™ CPUs with Radeon™ Graphics |
Memory
| Feature | Details |
| Memory Type | DDR5 |
| DIMM Slots | 2 x DDR5 DIMM sockets |
| Maximum Capacity | Up to 128 GB (64 GB per DIMM) |
| Channel Architecture | Dual Channel |
| Supported Speeds | DDR5 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MHz |
| ECC Support | Non-ECC, Un-buffered DIMM 1Rx8 / 2Rx8 / 1Rx16 |
| Overclocking Profiles | Supports AMD EXPO™ and Intel XMP |
| Memory Note | Memory speed and compatibility depend on CPU model and configuration |
Integrated Graphics
| Feature | Details |
| Graphics Processor | Integrated AMD Radeon™ Graphics (on supported CPUs) |
| Display Outputs | 1 x DisplayPort 1.4 (Max 3840x2160 @ 144Hz)</li><li>1 x HDMI 2.1 (Max 4096x2160 @ 60Hz) |
| Display Features | Supports HDCP 2.3 and native HDMI 2.1 TMDS |
| Graphics Support | Varies depending on CPU model |
| Multi-Display | Supports up to dual-display output simultaneously |
Audio
| Feature | Details |
| Audio Codec | Realtek® High Definition Audio CODEC |
| Channel Support | 2 / 4 / 5.1 / 7.1-channel HD Audio |
| Software Customization | Jack function configurable via Realtek Audio Software |
| 7.1 Surround | Supported through software configuration |
Networking
| Feature | Details |
| LAN Controller | Realtek® GbE LAN |
| Speed | 1 Gbps / 100 Mbps / 10 Mbps |
| Features | Integrated LAN bandwidth management software |
Expansion Slots
| Feature | Details |
| PCIe x16 Slot (CPU) | 1 x PCI Express x16 (PCIe 4.0, speed varies by CPU) |
| Supported Modes | Ryzen™ 7000 / 9000: PCIe 4.0 x16, Ryzen™ 8000 Phoenix 1: PCIe 4.0 x8</li><li>Ryzen™ 8000 Phoenix 2: PCIe 4.0 x4 |
| PCIe x1 Slot (Chipset) | 1 x PCI Express 3.0 x1 (PCIEX1) |
| Usage Note | PCIEX16 slot supports GPU or NVMe SSD (primary slot recommended for GPU) |
Storage
| Feature | Details |
| M.2 Slot | 1 x M.2 (Socket 3, M Key, Type 2580/2280) |
| Interface Support | PCIe 4.0 x4/x2 SSD (depends on CPU) |
| SATA Ports | 4 x SATA 6Gb/s |
| RAID Support | RAID 0, 1, 10 for both NVMe and SATA storage devices |
| Storage Note | CPU and M.2 configuration affect performance and compatibility |
USB Connectivity
| Feature | Details |
| CPU-Based Ports | 2 x USB 3.2 Gen 1 (Rear Panel)</li><li>1 x USB 2.0/1.1 (Rear Panel) |
| Chipset-Based Ports | 2 x USB 3.2 Gen 1 (Internal Header)</li><li>7 x USB 2.0/1.1 (3 Rear + 4 Internal) |
| Total USB Ports | Up to 12 USB ports (6 Rear + 6 Internal) |
Internal I/O Connectors
| Feature | Details |
| Power Connectors | 1 x 24-pin ATX Main Power, 1 x 8-pin ATX 12V |
| Cooling Headers | 1 x CPU Fan Header, 2 x System Fan Headers |
| Lighting Headers | 1 x Addressable LED Header, 1 x RGB LED Header |
| Storage Connectors | 1 x M.2 Socket, 4 x SATA 6Gb/s Ports |
| Front I/O Connectors | 1 x Front Panel Header, 1 x Front Audio Header |
| USB Headers | 1 x USB 3.2 Gen 1, 2 x USB 2.0 |
| Security Header | 1 x Trusted Platform Module (TPM) Header |
| Maintenance Jumpers | 1 x Clear CMOS Jumper |
Back Panel I/O
| Feature | Details |
| Legacy Ports | 1 x PS/2 Keyboard/Mouse Combo Port |
| Video Outputs | 1 x DisplayPort 1.4, 1 x HDMI 2.1 |
| USB Ports | 4 x USB 2.0, 2 x USB 3.2 Gen 1 |
| Networking | 1 x RJ-45 (Realtek® GbE LAN) |
| Audio Jacks | 3 x 3.5mm Audio Jacks |
| Utility Button | 1 x Q-Flash Plus BIOS Update Button |
I/O Controller & Monitoring
| Feature | Details |
| Controller | iTE® I/O Controller Chip |
| Voltage Monitoring | Supported |
| Temperature Monitoring | Supported |
| Fan Speed Detection | Supported |
| Water Cooling Flow Rate Detection | Supported |
| Fan Speed Control | Smart / Manual Control (depends on fan model) |
| Fan Failure Warning | Supported |
BIOS
| Feature | Details |
| BIOS Chip | 256 Mbit Flash |
| Type | AMI UEFI BIOS |
| Standards Compliance | PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Update Utilities | Q-Flash & Q-Flash Plus (update BIOS without CPU/RAM) |
Software & Utilities
| Feature | Details |
| Control Utility | GIGABYTE Control Center (GCC) |
| Bundled Software | Norton® Internet Security (OEM), LAN Bandwidth Management Software |
| RGB & Fan Control | Fully manageable through GCC |
Operating System Support
| Feature | Details |
| Supported OS | Windows 11 64-bit, Windows 10 64-bit |
Physical Specifications
| Feature | Details |
| Form Factor | Micro ATX |
| Dimensions | 23.0 cm x 22.5 cm |
| Mounting Standard | mATX Mounting Holes |
Warranty
| Duration | 3 Years |
