Technical Specifications
Chipset & CPU Support
| Chipset | AMD A620 |
| CPU Socket | AMD Socket AM5 |
| Supported Processors | AMD Ryzen™ 7000 / Ryzen™ 8000 / Ryzen 9000 Series |
| Future Compatibility | BIOS upgradable for future AMD Ryzen processors |
| CPU Notes | Refer to the official GIGABYTE “CPU Support List” for detailed compatibility |
Memory
| Memory Type | DDR5 |
| DIMM Slots | 2 x DDR5 DIMM sockets |
| Maximum Capacity | Up to 128GB (Supports up to 64GB per DIMM) |
| Memory Architecture | Dual Channel |
| Supported Speeds | DDR5 6400(OC)/6200(OC)/6000(OC)/5600(OC)/5200/4800/4400 MT/s |
| ECC Support | Non-ECC Un-buffered DIMMs only |
| Overclock Profiles | AMD EXPO™ & Intel XMP Supported |
Integrated Graphics
| Integrated GPU | Dependent on CPU model |
| DisplayPort | 1 x DisplayPort 1.4 (Max Resolution: 3840x2160 144Hz) |
| HDMI | 1 x HDMI 2.1 (Max Resolution: 4096x2160 60Hz, HDCP 2.3) |
| Multi-Display Support | Up to 3 simultaneous displays |
Audio
| Codec | Realtek Audio CODEC |
| Channel Support | 2 / 4 / 5.1 / 7.1-channel HD Audio |
| Customization | Jack functionality configurable via software |
| Audio Standards | High Definition Audio (HDA) compliant |
Networking
| LAN Controller | Realtek GbE LAN (1 Gbps / 100 Mbps / 10 Mbps) |
| Bandwidth Management | Bundled LAN Control Software |
| Wireless | Optional via PCIe or USB adapter (not included) |
Expansion Slots
| CPU Lane Slot | 1 x PCI Express x16 Slot |
| Supported Interface | PCIe 4.0 (varies by CPU) |
| Speed Support by CPU | Ryzen™ 7000, PCIe 4.0 x16, Ryzen™ 8000 Phoenix 1, PCIe 4.0 x8, Ryzen™ 8000 Phoenix 2, PCIe 4.0 x4 |
| Chipset Slot | 1 x PCIe 3.0 x1 Slot |
Storage
| M.2 Slot | 1 x M.2 (M Key, Type 2280), integrated in CPU |
| M.2 Interface | PCIe 4.0 x4/x2 (depending on CPU) |
| SATA Ports | 4 x SATA 6Gb/s Connectors |
| RAID Support | RAID 0, 1, 10 for both SATA & NVMe SSDs |
| Compatibility Note | M.2 slot and PCIe x16 lane share bandwidth depending on configuration |
USB Connectivity
| From CPU | 2 x USB 3.2 Gen1 (Rear Panel), 1 x USB 2.0 (Rear Panel) |
| From Chipset | 2 x USB 3.2 Gen1 (Internal Header), 7 x USB 2.0 (3 Rear + 4 Internal) |
| Total USB Ports | Up to 12 (5 Rear, 7 Internal) |
Internal I/O Connectors
| Power | 1 x 24-Pin ATX, 1 x 8-Pin ATX 12V |
| Cooling | 1 x CPU Fan Header, 2 x System Fan Headers |
| Lighting | 1 x Addressable RGB (5V), 1 x Standard RGB (12V) |
| Storage | 1 x M.2 Socket (PCIe 4.0), 4 x SATA 6Gb/s |
| Front I/O | 1 x Front Panel Header, 1 x Front Audio Header |
| USB Headers | 1 x USB 3.2 Gen1 Header, 2 x USB 2.0 Headers |
| Security | 1 x TPM Header (for GC-TPM2.0 SPI Module) |
| Maintenance | 1 x Clear CMOS Jumper |
Back Panel I/O
| USB Ports | 4 x USB 2.0, 2 x USB 3.2 Gen1 |
| Video Ports | 1 x HDMI 2.1, 1 x DisplayPort 1.4 |
| Networking | 1 x RJ-45 LAN Port |
| Audio | 3 x 3.5mm Audio Jacks |
| Legacy Port | 1 x PS/2 Keyboard/Mouse Combo |
| Flash Feature | Q-Flash Plus Button |
BIOS
| BIOS Type | AMI UEFI BIOS |
| Flash Memory | 256 Mbit |
| Standards Supported | PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
| Utilities | Q-Flash, Q-Flash Plus |
Software & Utilities
| Main Utility | GIGABYTE Control Center (GCC) |
| Bundled Software | Norton Internet Security (OEM), LAN Bandwidth Management Tool |
Operating System Support
| Supported OS | Windows 11 64-bit, Windows 10 64-bit |
Physical & Form Factor
| Form Factor | Micro ATX |
| Dimensions | 23.0cm x 22.5cm |
| Mounting | Standard mATX Mounting Holes |
Warranty information
| Warranty | 3 years |
