Technical Specifications
Specification Summary
| Form Factor | Micro ATX (24.4cm × 24.4cm) |
| Operating System Support | Windows 11 64-bit, Windows 10 64-bit |
Processor (CPU)
| Supported CPUs | AMD Ryzen™ 9000 / 8000 / 7000 Series Desktop Processors |
Memory
| Slots | 4 × DIMM |
| Capacity | Up to 256 GB (64 GB per DIMM) |
| Architecture | Dual Channel |
| Speed Support (MT/s) | 8200(OC), 8000(OC), 7800(OC), 7600(OC), 7200(OC), 7000(OC), 6800(OC), 6666(OC), 6600(OC), 6400(OC), 6200(OC), 6000(OC), 5600(OC), 5200, 4800, 4400 |
| Module Type | Non-ECC Un-buffered DIMM 1Rx8 / 2Rx8 / 1Rx16 |
Onboard Graphics
| Outputs | 1 × HDMI 2.1 (4096×2160@60 Hz, HDCP 2.3, HDR) |
| Multi-Display Support | Up to 3 Displays Simultaneously |
Expansion Slots
| From CPU | 1 × PCIe x16 slot (PCIEX16) Ryzen 9000/7000 = PCIe 5.0 x16 Ryzen 8000 Phoenix 1 = PCIe 4.0 x8 Ryzen 8000 Phoenix 2 = PCIe 4.0 x4 |
| From Chipset | 1 × PCIe x16 slot (PCIEX4) – PCIe 3.0 x4 |
Storage Interface
| M.2 Slots | M2A_CPU: PCIe 5.0 / 4.0 x4/x2 (Ryzen 9000 / 7000 / 8000) — Type 2580 / 2280 M2B_CPU: PCIe 4.0 x4/x2 (9000 / 7000 / 8000 Phoenix 1), PCIe 4.0 x2 (Phoenix 2) — Type 22110 / 2280 |
| SATA Ports | 4 × SATA 6 Gb/s |
| NVMe RAID Support | RAID 0 / 1 / 5 / 10 (RAID 5 only on Ryzen 9000) |
USB Connectivity
| Back Panel | 1 × USB-C (3.2 Gen 1) • 3 × USB 3.2 Gen 1 • 2 × USB 2.0 • 1 × USB 2.0/1.1 • 1 × USB 3.2 Gen 1 (from CPU) |
| Internal Headers | 1 × USB-C (3.2 Gen 1) • 1 × USB 3.2 Gen 1 • 2 × USB 2.0/1.1 |
| Total USB Support | Up to 13 × USB ports total (depending on headers and configuration) |
Back Panel Ports
| Legacy I/O | 1 × PS/2 Keyboard/Mouse Combo |
| USB Ports | 1 × USB-C (3.2 Gen 1) • 3 × USB 3.2 Gen 1 • 2 × USB 2.0 |
| LAN | 1 × RJ-45 (1 GbE) |
| Audio | 3 × Audio Jacks |
| Special Button | Q-Flash Plus Button |
Warranty Information
| Duration | 3 Years |
