Technical Specifications
Basic Information
| Supported CPU | Intel Core Ultra Processors (Series 2) |
| Chipset | Intel Z890 |
| Form Factor | ATX (243.84mm × 304.8mm) |
| Audio Codec | Realtek ALC1220P |
| Audio Channels | 7.1-Channel HD |
| S/PDIF Output | Supported |
Expansion Slots
| PCIe Slots | 3× PCI-E x16 |
| PCI_E1 | PCIe 5.0 x16 (CPU) |
| PCI_E2 | PCIe 4.0 x4 (Chipset) |
| PCI_E3 | PCIe 4.0 x4 (Chipset) |
Memory
| Type | DDR5 |
| Supported Speeds | 9200–6400 (OC) MT/s; 6400–4800 (JEDEC) MT/s |
| Max OC Frequency | 1DPC 1R: 9200+ MT/s 1DPC 2R: 7200+ MT/s 2DPC 1R: 4800+ MT/s 2DPC 2R: 4800+ MT/s |
| Max Capacity | 256GB |
| Channel Support | Dual-Channel |
| XMP Support | Intel XMP 3.0 |
| Compatibility | Non-ECC, Un-buffered, CUDIMM |
Graphics Output
| HDMI | 1× HDMI 2.1 (4K 120Hz) |
| Type-C DisplayPort | 2× Thunderbolt 4 DP 1.4 |
| Max Resolution | 4K 120Hz / 8K 60Hz* |
USB Ports
| Front USB | 4× USB 2.0; 2× USB 5Gbps Type-A; 1× USB 20Gbps Type-C (27W PD) |
| Rear USB | 4× USB 5Gbps Type-A; 3× USB 10Gbps Type-A; 1× USB 10Gbps Type-C |
Networking
| LAN | Intel Killer E5000 5Gbps |
| Wireless | Intel Killer BE1750x Wi-Fi 7 |
| Bluetooth | Bluetooth 5.4 |
Storage
| M.2_1 | PCIe 5.0 x4 (2280/2260) |
| M.2_2 | PCIe 4.0 x4 (22110/2280/2260) |
| M.2_3 | PCIe 4.0 x4 (2280/2260/2242) |
| M.2_4 | PCIe 4.0 x4 / SATA (2280/2260/2242) |
| SATA | 4× SATA 6Gbps |
| RAID | RAID 0/1/5/10 for SATA & M.2 |
Internal I/O
| Power | 1× ATX_PWR; 2× CPU_PWR; 1× PCIE_PWR 8-pin |
| Cooling | 1× CPU Fan; 1× Pump/Fan; 6× System Fan |
| Front Panel | 2× JFP |
| RGB | 3× ARGB V2; 1× RGB |
| Thunderbolt | 1× JTBT5 (Thunderbolt 5 Card) |
| TPM | TPM 2.0 Header |
| USB Headers | 4× USB 2.0; 2× USB 5Gbps; 1× USB 20Gbps Type-C |
Warranty
| Duration | 3 Years |
