JONSBO Z20 M-ATX Gaming Case (Pink Black)

Product Description

Ultimate JONSBO Z20 M-ATX Gaming Case (Pink Black) for Compact Airflow Performance

Your compact PC build is choking inside a cramped, airflow-starved case — and the JONSBO Z20 M-ATX Gaming Case (Pink Black) was built to fix that.

This small-form-factor chassis refuses to compromise on style or hardware capacity.

Builders hunting best gaming pc components that actually fit a tighter footprint will find this Micro-ATX case a genuinely well-thought-out solution.

PCB Store brings this eye-catching unit to Bangladesh, giving local builders a premium enclosure that punches above its weight class.

The pink-black colorway alone turns heads.

But under that tempered glass panel lies a seriously capable chassis for performance-oriented setups.

JONSBO Z20 Specifications: What Fits Inside

Before committing to any Desktop Gaming Casing, you need hard numbers on clearance, dimensions, and material.

Get these right first — everything else follows from here.

Core Dimensions and Build Data

• Dimensions (without handle/feet): 370mm × 186mm × 295mm
• Dimensions (with handle/feet): 382mm × 198mm × 335mm
• Net Weight: 5 kg | Gross Weight: 6.5 kg
• Material: SPCC Steel body with Tempered Glass side panel
• Motherboard Support: Mini-ITX / Micro-ATX
• GPU Clearance: Up to 363mm
• CPU Air Cooler Height: 164mm (Intel) / 163mm (AMD)
• PSU Support: SFX / SFX-L (recommended ≤140mm ATX)
• Storage: Up to 3× 2.5" SSD bays + 1× 3.5" HDD bay

This case targets builders who want a compact footprint without gutting their component list.

Cooling Configuration: Serious Airflow in a Small Frame

Most compact cases sacrifice cooling. The JONSBO Z20 M-ATX Gaming Case does not.

Knowing the Best Jonsbo Casing Price in BD matters, but airflow architecture is what separates an average enclosure from a capable one.

Fan Slot Breakdown and Radiator Support

• Top: 2× 120mm or 2× 140mm fans
• Bottom: 2× 120mm or 2× 140mm fans
• Rear: 1× 120mm or 1× 92mm fan

That gives you up to five fan positions across three intake and exhaust zones.

The top position also accepts a 240mm radiator, opening the door for liquid cooling setups in an M-ATX form factor.

Thermal headroom is real here — not a checkbox feature.

Builders who push their CPUs and GPUs hard will appreciate this layout. Air moves through the chassis with purpose.

GPU and PSU Clearance: Real Hardware Fits Here

A 363mm GPU clearance means most flagship cards have room.

RTX 4070s, RX 7800 XTs, and similarly sized cards slot in without forcing a compromise.

The JONSBO Z20 M-ATX Gaming Case was clearly sized with modern GPU lengths in mind.

PSU and CPU Cooler Compatibility

PSU compatibility matters just as much.

SFX and SFX-L power supplies are natively supported, keeping the internal layout clean.

If you run a standard ATX unit, keep it at or below 140mm — anything longer creates clearance conflicts.

The 164mm CPU cooler ceiling handles most tower air coolers.

Builders eyeing a Noctua NH-U12S, DeepCool AK400, or similar unit should fit comfortably within that limit.

Build Quality: SPCC Steel and Tempered Glass

The JONSBO Z20 uses SPCC steel for its chassis — a cold-rolled carbon steel with good rigidity and surface finish.

It does not flex or creak when handled, and the 5 kg net weight reflects solid construction.

Aesthetic Finish and Panel Design

The tempered glass panel adds that showcase factor without the fragility of acrylic.

Your RGB components and cable routing stay on display.

The pink-black colorway makes this case stand out in a sea of all-black and all-white builds.

It is a deliberate aesthetic choice — not an afterthought.

Checking Official Jonsbo Products Price in Bangladesh before finalizing your build ensures you get authentic quality and accurate market pricing, not a grey-market substitute.

Storage Options: SSDs and HDDs Covered

Three 2.5" SSD bays handle modern NVMe and SATA SSDs without requiring adapters.

One 3.5" HDD bay keeps mass storage viable — useful for content creators or gamers with large local libraries.

This storage layout fits the M-ATX use case well.

You get enough drive capacity without bloating the chassis size.

Who Should Buy the JONSBO Z20 M-ATX Gaming Case?

This case targets a specific type of builder.

If your setup involves Mini-ITX or Micro-ATX and you care about airflow, GPU size, and visual appeal, this case checks every box.

• Mid-tower minimalists who want performance in a smaller footprint
• Aesthetics-focused builders who want a pink-black case with a glass side panel
• Liquid cooling enthusiasts who need 240mm radiator support in compact builds
• High-GPU users who need 363mm of clearance without going full ATX
• Dual-storage builders combining SSDs with one mechanical drive

Builders comparing alternatives may also consider the ASUS A31 ATX Mid-Tower Gaming Casing (Black) — a full ATX option with its own airflow strengths.

Though the Z20 wins clearly on footprint and style for compact setups.

Where to Buy JONSBO Z20 M-ATX Gaming Case Online in BD?

PCB Store in BD carries the JONSBO Z20 M-ATX Gaming Case (Pink Black), available for order online.

It ships as a PC Components casing with a gross weight of 6.5 kg.

No local warranty is included with this unit, so handle the tempered glass panel carefully during installation.

As the best pc builder in Bangladesh, PCB Store provides reliable after-sales service across the country.

Our team handles warranty claims, technical issues, and product support directly.

If you are building a compact rig in Dhaka or anywhere across Bangladesh, this is one of the more capable M-ATX cases on the local market right now.

Check PCB Store's current listing for the latest price and availability.
