Technical Specifications
Basic Information
| Model | Intel Core Ultra 5 245 |
| Code Name | Arrow Lake |
| Segment | Desktop Processor |
| Lithography | TSMC N3B |
CPU Specifications
| Total Cores | 14 (6P + 8E) |
| Total Threads | 14 |
| Max Turbo Frequency | Up to 5.10 GHz |
| Base Frequency | 3.5 GHz (P-core), 3.0 GHz (E-core) |
| Cache | 24MB Smart Cache |
| L2 Cache | 26MB |
| Base Power | 65W |
| Max Turbo Power | 121W |
Memory Specifications
| Max Memory | 256GB |
| Memory Type | DDR5 up to 6400 MT/s |
| Memory Channels | 2 |
| ECC Support | Yes |
Graphics Specifications
| Integrated GPU | Intel Graphics |
| GPU Frequency | Up to 1.9 GHz |
| Xe Cores | 4 |
| Max Resolution | 8K @ 60Hz |
| API Support | DirectX 12, OpenGL 4.5, OpenCL 3 |
| Video Support | AV1, HEVC, H.264 Encode/Decode |
AI & NPU
| NPU | Intel AI Boost |
| NPU Performance | 13 TOPS (Int8) |
| Total AI Performance | 29 TOPS |
| AI Frameworks | OpenVINO, WindowsML, ONNX RT |
Expansion & Connectivity
| PCIe Version | 5.0 & 4.0 |
| PCIe Lanes | 24 |
| Thunderbolt | Thunderbolt 4 |
| DMI | DMI 4.0 (8 lanes) |
Advanced Technologies
| Hyper-Threading | No |
| Turbo Boost | Intel Turbo Boost 2.0 |
| Instruction Set | 64-bit, AVX2, SSE4.1/4.2 |
| Virtualization | VT-x, VT-d, EPT |
Security Features
| Security Tech | AES-NI, Boot Guard, TME |
| vPro Support | vPro Enterprise |
| Threat Detection | Yes |
Warranty
| Warranty | 3 Years |
