Technical Specifications
Hardware Features
| Antenna Type | Built-in 2dBi Antenna |
| Interface | USB 2.0 |
| Dimensions (L × W × H) | 20 × 15 × 8 mm |
| Weight | 3 g |
| LED Indicator | Link / Activity (if applicable)Link / Activity (if applicable) |
| Form Factor | Ultra-Mini Nano Adapter (Compact Design) |
Wireless
| Wireless Standard | IEEE 802.11a / b / g / n / ac |
| Frequency Bands | 2.4GHz (2.412–2.4835GHz) & 5GHz (5.180–5.825GHz) |
| Maximum Data Rate | Up to 650Mbps Combined • 200Mbps @ 2.4GHz • 433Mbps @ 5GHz |
| 11b Data Rates | 1 / 2 / 5.5 / 11 Mbps |
| 11g Data Rates | 6 / 9 / 12 / 18 / 24 / 36 / 48 / 54 Mbps |
| 11n Data Rates | Up to 200 Mbps |
Wireless Security
| Security Standards | WPA-PSK / WPA2-PSK, WPA / WPA2, WEP |
| Encryption | 64-bit / 128-bit WEP, TKIP, AES |
| Wi-Fi Protected Setup (WPS) | Not Supported (Manual Configuration Required) |
System Requirements
| Supported Operating Systems | Windows XP / Vista / 7 / 8 / 8.1 / 10 |
| MacOS Compatibility | MacOS 10.6 ~ MacOS 10.15 |
| Driver Installation | Manual Driver Required (Not Plug & Play) |
| Supported Devices | Desktop PCs, Laptops (USB 2.0 Port Required) |
Physical Specification
| Color | Black |
| Material | Plastic Housing |
| Operating Temperature | 0°C – 40°C |
| Storage Temperature | -20°C – 70°C |
Warranty Information
| Warranty | 1 year |
