Technical Specifications
Processor
| Socket | LGA1851 |
| Supported CPU | Intel Core Ultra Processors |
| L3 Cache | Varies with CPU |
Chipset & BIOS
| Chipset | Intel H810 Express Chipset |
| BIOS | 256 Mbit flash, AMI UEFI |
| Standards | PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
Memory
| Type | DDR5 6400/5600 MT/s |
| Slots | 2 x DDR5 DIMM |
| Capacity | Up to 128 GB |
| Architecture | Dual Channel |
| ECC Support | ECC Unbuffered DIMM (non-ECC mode) |
| Non-ECC Support | Un-buffered DIMM 1Rx8/2Rx8/1Rx16 |
| XMP | Supported |
Graphics
| Integrated GPU | Intel HD Graphics |
| HDMI | 4096x2160@60Hz, HDMI 2.1, HDCP 2.3 |
| D-Sub | 1920x1200@60Hz |
Networking
| LAN | Realtek GbE LAN, 1 Gbps/100 Mbps/10 Mbps |
Internal I/O Ports
| Power | 24-pin ATX, 8-pin ATX 12V |
| Cooling | 1 x CPU fan, 2 x system fan |
| RGB | 2 x Addressable RGB Gen2 headers |
| Storage | 1 x M.2 Socket 3, 4 x SATA 6Gb/s |
| Audio | Front panel audio, S/PDIF Out header |
| USB | 1 x USB Type-C® (USB 3.2 Gen 1), 1 x USB 3.2 Gen 1 header, 1 x USB 2.0/1.1 header |
| Security | TPM header |
| Other | Serial port header, Clear CMOS jumper |
External I/O Ports
| PS/2 | 1 x Keyboard/Mouse port |
| HDMI | 1 x HDMI port |
| D-Sub | 1 x D-Sub port |
| USB | 1 x USB 3.2 Gen 1, 5 x USB 2.0/1.1 |
| LAN | 1 x RJ-45 port |
| Audio | 3 x Audio jacks |
Physical Specification
| Form Factor | Micro ATX |
| Dimensions | 24.4 cm x 21.5 cm |
Warranty Information
| Duration | 03 Years |
