Technical Specifications
Scanning System
| Scanning Principle | Single pass with 3 independent photo multipliers |
| Spot Size | 18 sizes starting at 3 microns |
| Scanning Area | 12” × 12” (304 mm × 304 mm) |
| Capture Fidelity | 16-bit separate RGB output |
Resolution & Image Processing
| Optical Step Resolutions | 20 steps from 80² up to 16,000 × 8,000 |
| Interpolated Resolution | Up to 64,000 dpi bi-cubic interpolation |
| Scaling Capability | 2,666% optical; up to 21,333% interpolated at 300 dpi |
| Maximum File Size | 96 GB (48-bit) |
Media & Scan Modes
| Supported Media | Transparencies, negatives, reflective media, slides, printed materials |
| Scan Modes | RGB density, CMYK density, RGB log, gray-tone |
| Color Management | ICC / ICM tagging and conversion |
| Supported File Formats | TIFF (8/16/24/48-bit), CMYK, Gray, PSD, Loss-Less, WMF, BMP |
Hardware & Interface
| Interface | ANSI SCSI-2 |
| Platform Requirements | Windows 98, ME, 2000, XP, Vista, 7 |
| Processor Requirement | Intel processor 500 MHz or higher |
| Memory Requirement | 4 GB RAM |
| Storage Requirement | 80 GB or larger hard drive |
Physical & Power
| Light Source | Dual halogen photo optic lamps |
| Electrical Requirement | 120/240 VAC, 50/60 Hz automatic |
| Weight | 168 lbs (76.2 kg) |
Warranty
| Warranty | Manufacturer standard warranty via PCB Store Bangladesh |
