Technical Specifications
Basic Information
| Supported CPU | AMD Ryzen 9000/8000/7000 Series |
| Chipset | AMD B850 |
| BIOS | 256 Mb Flash ROM, UEFI AMI BIOS |
| Form Factor | ATX (30.5 cm × 24.4 cm) |
Audio
| Codec | Realtek ALC1220P |
| Channels | 7.1 Surround Sound |
| Playback | 120 dB SNR |
| Recording | 113 dB SNR |
| Features | Impedance sense, Audio shielding, Premium capacitors, Audio PCB layers, Audio cover, De-pop circuit |
Expansion Slots
| PCIe (CPU) | 1 × PCIe 5.0 x16 (Ryzen 9000/7000) |
| PCIe (CPU Alt) | 1 × PCIe 4.0 x16 (x8/x4, Ryzen 8000) |
| PCIe (Chipset) | 1 × PCIe 4.0 x16 (x4), 1 × PCIe 4.0 x1 |
Memory
| Type | DDR5 |
| Slots | 4 × DIMM |
| Capacity | Up to 256GB |
| Speed | Up to 8000+ MT/s (OC) |
| Features | Dual-channel, EXPO, AEMP |
Graphics Output
| DisplayPort | 1 × DP 1.4 (8K@30Hz) |
| HDMI | 1 × HDMI 2.1 (4K@60Hz) |
Networking
| LAN | Realtek 2.5Gb Ethernet, TUF LANguard |
| Wireless | Wi-Fi 7 (2×2), BT 5.4 |
Storage
| M.2 Total | 3 × M.2 |
| SATA | 4 × SATA 6Gb/s |
| RAID | RAID 0/1/5/10 (Ryzen 9000), RAID 0/1 (Ryzen 8000), RAID 0/1/10 (Ryzen 7000) |
Internal I/O
| Fan Headers | CPU, CPU OPT, AIO Pump, 4 × Chassis |
| RGB | 3 × ARGB Gen 2 |
| Power | 24-pin + 2 × 8-pin CPU |
| Additional | Clear CMOS, COM header, Front audio, TB header |
Warranty Information
| Warranty | 3 Years |
