Technical Specifications
General
| CPU Support | AMD Socket AM5 (Ryzen 9000 / 8000 / 7000 Series) |
| Chipset | AMD X870 |
| BIOS | 256 Mb Flash ROM, UEFI AMI BIOS |
Form Factor
| Form Factor | ATX |
| Dimensions | 12 x 9.6 inch (30.5 cm x 24.4 cm) |
Memory
| Memory Type | DDR5 |
| Memory Slots | 4 x DIMM |
| Max Memory | 192GB |
| Memory Speed | Up to 8000+ MT/s (OC) |
| Architecture | Dual Channel |
| Memory Profile | AMD EXPO, ASUS AEMP |
Expansion Slots
| PCIe (Ryzen 9000/7000) | 1 x PCIe 5.0 x16 |
| PCIe (Ryzen 8000) | 1 x PCIe 4.0 x16 (x8/x4 mode) |
| Chipset PCIe | 1 x PCIe 4.0 x16 (x4 mode) |
Storage
| M.2 Slots | 4 x M.2 (PCIe 5.0 & 4.0 support by CPU) |
| SATA Ports | 2 x SATA 6Gb/s |
| RAID Support | RAID 0/1/5/10 (RAID 5 Ryzen 9000 only) |
Graphics Output
| DisplayPort | 1 x DP 1.4 (up to 8K@30Hz) |
| HDMI | 1 x HDMI 2.1 (4K@60Hz) |
| USB4 Display | 2 x USB4 Type-C (40Gbps, DP Alt Mode) |
Networking
| LAN | Intel 2.5Gb Ethernet |
| Wireless | 2x2 Wi-Fi 7 (802.11be, up to 2.9Gbps) |
| Bluetooth | v5.4 |
USB & I/O
| Rear USB | 12 Ports (USB4, 10Gbps, 5Gbps mix) |
| Front USB | Up to 9 Ports (20Gbps Type-C supported) |
| Audio | ROG SupremeFX ALC4080, 7.1 Channel |
| Optical Out | 1 x S/PDIF |
Internal Connectors
| CPU Power | 2 x 8-pin +12V |
| Main Power | 24-pin |
| Fan Headers | 1 x CPU, 1 x CPU OPT, 1 x AIO, 5 x Chassis |
| RGB Headers | 3 x Addressable Gen 2 |
Special Features
| Cooling | M.2 Heatsink + Backplate |
| DIY Features | BIOS FlashBack, Clear CMOS, Q-Design |
| Software | Armoury Crate, Aura Sync, AI Overclocking |
Warranty
| Manufacturing Warranty | 3 Years |
