Technical Specifications
Core Components
| Chipset & Socket | AMD B850, Socket AM5 (Supports Ryzen 9000/8000/7000 Series) |
| Form Factor | Micro-ATX (24.4 × 24.4 cm), Pre-mounted I/O Shield |
| Memory Support | 4× DDR5 DIMMs, up to 8000+ MT/s OC, Max 256GB, Dual-Channel, EXPO, ECC |
Expansion & Storage
| PCIe Slots | 1× PCIe 5.0 x16 (9000/7000), 3× PCIe 4.0 x1 |
| M.2 & SATA | 3× M.2 (PCIe 5.0/4.0), 4× SATA 6Gb/s, RAID 0/1/5/10 (varies by CPU) |
Graphics, USB & Network
| Graphics Output | HDMI 2.1 (4K@60Hz), DP (8K@30Hz) |
| USB Ports | Rear: 2× USB 10Gbps, 2× USB 5Gbps, 5× USB 2.0; Front: USB-C, USB 3.2, USB 2.0 |
| Networking | Realtek 1Gb LAN (LANGuard), Wi-Fi 6 (802.11ax), Bluetooth 5.4 |
Audio, Cooling & Features
| Audio | Realtek 7.1 HD, 24-bit/192kHz, Audio shielding, Premium capacitors |
| Cooling & RGB | 6× Fan Headers, AIO Pump Support, 3× Gen 2 ARGB, VRM Heatsink, Aura Sync |
| Special Tools | Q-LED, BIOS FlashBack, Armoury Crate, Fan Xpert 2+, AI Advisor |
Warranty
| Duration | 3 Years |
