Technical Specifications
PROCESSOR
| Model | AMD EPYC™ 9575F (9005 Series "Turin") |
| Cores / Threads | 64 Cores / 128 Threads |
| Base / Boost Clock | 3.30 GHz / 5.00 GHz (4.50 GHz All-Core) |
| Cache (L1/L2/L3) | 80KB L1/core + 1MB L2/core + 256MB L3 |
| Architecture | Zen 5, 4nm, AVX-512, BFLOAT16, VNNI |
| TDP | 400W Default (Configurable: 320W – 400W) |
| Max Junction Temp | 100°C |
MOTHERBOARD
| Form Factor | ATX (12" x 10.1" / 30.48cm x 25.65cm) |
| Socket | Single Socket SP5 (LGA 6096) |
| Chipset | System on Chip (SoC) |
| PCIe Lanes | 128x PCIe 5.0 (Direct from CPU) |
| CXL Support | CXL 2.0 — Type 3 Memory Expansion |
| BIOS | AMI 32MB SPI Flash, UEFI 2.8, ACPI 6.4 |
MEMORY
| DIMM Slots | 12x DDR5 (1 DIMM per Channel) |
| Max Capacity | Up to 256GB per RDIMM (3TB Total) |
| Speed | Up to 6000 MT/s (6400 MT/s select configs) |
| Bandwidth | 576.0 GB/s per Socket |
| ECC Support | Single-bit Correction / Double-bit Detection |
EXPANSION SLOTS
| PCIe Slots | 3x PCIe 5.0 x16 + 2x PCIe 5.0 x8 |
| M.2 Slots | 2x PCIe 4.0 x4 NVMe/SATA (2280/22110) |
| MCIO Ports | 2x PCIe 5.0 x8 + 1x PCIe 5.0 x8/SATA3 Hybrid |
STORAGE
| SATA Ports | 8x SATA3 (via Hybrid MCIO/Header) |
| DOM Ports | 2x SuperDOM (Built-in Power) |
NETWORKING & I/O
| LAN | 2x 1GbE Base-T (Broadcom BCM5720) |
| Management LAN | 1x Dedicated 1GbE IPMI (Realtek RTL8211F) |
| USB | 4x USB 3.0 Rear + 2x USB 3.0 Header |
| Video / Serial | 1x VGA + 1x COM Header |
MANAGEMENT
| Remote Management | IPMI 2.0, KVM over Dedicated LAN |
| Software Suite | SuperCloud Composer, SSM, SPM, SUM, SuperDoctor 5 |
| Diagnostics | SDO (Super Diagnostics Offline), SAA |
POWER SUPPLY
| Configuration | 2x 800W Redundant (1+1 Hot-Swap) |
| Efficiency Rating | 80 Plus Titanium / Platinum |
SECURITY & COOLING
| Security | TPM 2.0 Header + Root of Trust (RoT) Hardware |
| Fan Headers | 6x 4-pin PWM with Tachometer Status |
| Voltage Monitoring | +12V, +3.3V, +5V, +5VSB, CPU/VRM Temp, VBAT |
| LED Indicators | BMC/IPMI Heartbeat Status |
WARRANTY
| Warranty | As per PCB Store Bangladesh warranty policy |
