Technical Specifications
General Information
| Product Name | Cudy MF4 4G LTE Sim Supported Mobile Wi-Fi Router |
| Category | Network And Router |
| Sub-Category | Pocket Router |
| Color | Black |
| Weight | 92g |
| Dimension | 9.7 × 6.1 × 1.6 cm |
Network & Connectivity
| Network Standard | 4G / 3G / 2G |
| LTE Data Rate | Downlink up to 150Mbps / Uplink up to 50Mbps |
| 3G Data Rate | Downlink up to 42Mbps / Uplink up to 5.76Mbps |
| Supported LTE Bands | B1 / B3 / B7 / B8 / B20 / B38 / B40 / B41 |
| Supported UMTS Bands | B1 / B3 / B8 |
| LTE Bandwidth | 1.4 / 3 / 5 / 10 / 15 / 20 MHz |
Wireless & Interface
| Wi-Fi Standard | IEEE 802.11 b/g/n |
| Frequency | 2.4GHz |
| Channel | 1–13 |
| USB Interface | USB 2.0 |
| SIM Slot | Single 4FF USIM |
Hardware
| Cellular Chipset | Qualcomm MDM9x07 / MDM9x25 |
| Wi-Fi Chipset | RealTek 8192ES |
| Antenna | Internal Primary & Diversity |
RF & Modulation
| Downlink Modulation | QPSK / 16-QAM / 64-QAM |
| Uplink Modulation | QPSK / 16-QAM |
| LTE RF Power | Power Class 3 (23 ±2 dBm) |
| UMTS RF Power | Power Class 3 (24 +1.7 / -3.7 dBm) |
| EDGE RF Power | GSM850/900: 27dBm; DCS/PCS: 26dBm |
System Compatibility
| Windows Support | XP / 7 / 8 / 10 |
| macOS Support | macOS 10.7+ |
| Linux Support | Ubuntu 13.04+ |
| Browser Support | IE9+, Firefox, Chrome, Safari, Opera |
Power & Environment
| Power Supply | USB 5V / 1A |
| Working Temperature | 0°C to 35°C |
| Storage Temperature | -20°C to 60°C |
Warranty
| Manufacturer Warranty | 1 Year |
