Technical Specifications
Specification Summary
| GPU | NVIDIA GeForce RTX 5070 |
| Architecture | NVIDIA Blackwell |
| CUDA Cores | 6144 |
| Video Memory Type | GDDR7 |
| Video Memory Size | 12GB |
Video Memory Specifications
| Core Clock | 2587 MHz |
| Memory Clock | 28 Gbps |
| Memory Bus | 192-bit |
| Maximum Resolution | Up to 4K @ 480Hz or 8K @ 165Hz (with DSC) |
Display & Interface
| DisplayPort | 3 x DisplayPort 2.1b (UHBR20) |
| HDMI | 1 x HDMI 2.1b (Supports 4K 120Hz HDR, 8K 60Hz HDR, VRR) |
| HDCP Support | 2.3 |
| Multi-Display Capability | Quad Display |
| Bus Interface | PCI Express 5.0 x16 |
Power Specifications
| Power Connector | 1 x 12V-2x6 PCIe Power Input |
| Recommended PSU | 650W |
| Power Consumption | 250W (High power consumption — please verify PSU compatibility before installation) |
Application Programming Interfaces
| DirectX® Support | Microsoft DirectX® 12 Ultimate |
| OpenGL® Support | 4.6 |
Cooling & Build Features
| Cooling Technology | IceStorm 3.0 Advanced Cooling |
| Vapor Chamber | Larger Vapor Chamber for better thermal performance |
| Fans | BladeLink Fans with FREEZE Fan Stop & Active Fan Control |
| Dual BIOS | Performance and Silent modes |
| Lighting | SPECTRA 2.0 RGB Lighting + SPECTRA LINK Lighting Sync Port |
| Backplate | Metal Die-Cast Backplate |
| Aesthetic Design | Infinity Mirror Finish |
| Safety | 12V-2x6 Safety Light Indicator |
| Bundled Accessory | GPU Support Bracket |
Physical Specifications
| Dimensions (mm) | 332.1 x 137.5 x 69.6 mm |
| Dimensions (inches) | 13.1" x 5.4" x 2.7" |
| Slot Size | 2 Slot |
Warranty Information
| Warranty | 3-year standard warranty + 2 years will be extended after online registration by the customer within 28 days of Purchase |
