Technical Specifications
Basic Information
| Processor Model | Core i5-1135G7 |
| Generation | 11th Gen |
| RAM | 8GB DDR4 3200MHz (1 × 8GB Installed, 2 Slots Total) |
| Storage (ROM) | 512GB NVMe PCIe Gen3x4 M.2 2280 SSD |
| Operating System | Windows® 11 Home |
| Processor Brand | Intel |
| Processor Frequency | 2.40 GHz up to 4.20 GHz |
| Processor Core | 4 |
| Processor Thread | 8 |
| CPU Cache | 6MB |
Display
| Type | Matte LED-Backlit Display |
| Resolution | Full HD (1920 × 1080) |
| Size | 14.0 inch (35.56cm) |
| Color Gamut | 45% NTSC |
| Panel Type | Anti-Glare IPS-Level |
Memory
| Installed RAM | 8GB DDR4 3200MHz SODIMM |
| Total RAM Slots | 2 |
| Maximum RAM Support | Up to 32GB (Expandable) |
Graphics
| Graphics Processor | Intel® Iris® Xe Graphics |
| Integrated Graphics | Yes (on Intel® Core™ i5 Processor) |
| Dedicated GPU | No |
Storage
| Installed Storage | 512GB NVMe PCIe Gen3x4 M.2 2280 SSD |
| Supported SSD Type | NVMe PCIe Gen4x4 M.2 2280 |
| Total Storage Slot | 1 |
| Maximum Supported Storage | Up to 1TB |
Keyboard & Pointing Device
| Keyboard Type | A4 Size Isolated Keyboard with English Font |
| Language Support | Multi-Language |
| Pointing Device | Built-in Touchpad with Microsoft PTP Multi-Gesture & Scrolling Function |
Audio
| Speakers | 2 × 2W Stereo Speakers |
| Audio Technology | High Definition Audio |
| Microphone | Built-in Array Microphone |
I/O Ports & Interface
| USB Ports | 1 × USB 3.2 Gen2 Type-A 1 × USB 3.2 Gen2 Type-C 1 × USB 2.0 Type-A |
| HDMI Port | 1 × HDMI™ Output (HDCP Supported) |
| Audio Jack | 1 × 2-in-1 Headphone / Microphone Combo Jack |
| LAN Port | 1 × RJ-45 Ethernet Port |
| DC-in Jack | 1 × Power Input |
| Card Reader | MicroSD Card Reader |
Expansion Slots
| M.2 Slots | 2 Slots Total |
| Slot 1 | WLAN Combo M.2 2230 (PCIe / USB / CNVi, E-Key) |
| Slot 2 | M.2 2280 SSD (SATA / PCIe Gen3x4, M-Key) |
Network & Communication
| Ethernet LAN | 10/100/1000Mbps Gigabit LAN |
| Wireless | Intel® Dual Band Wireless-AC 9462 (1×1 AC + Bluetooth® 5.1) |
| Bluetooth | Version 5.1 |
Camera
| Webcam | 1.0 Megapixel HD Camera |
| Video Support | HD 720p Recording |
Power Supply
| Battery Type | 3-Cell Smart Lithium-Ion Battery Pack |
| Battery Capacity | 49WH |
| Battery Life | Up to 420 Minutes (Tested with MobileMark 2014) |
| Adapter | 45W AC Adapter (Input: 110–240V, 50–60Hz / Output: 19V 2.37A) |
Security
| Lock Slot | Kensington® Lock |
| Security Chip | Firmware TPM 2.0 |
Physical Specification
| Weight | 1.4 kg |
| Dimensions (W × D × H) | 324.9 × 219.5 × 19.4 mm |
| Color | Black / Silver (Variant Dependent) |
| Build Material | Premium Lightweight Chassis |
| Hinge Design | 180° Lay-Flat Hinge |
In the Box
| Included Accessories | Laptop Charger, Device Drivers & Utilities, User Manual |
Special Features
| High-Performance 11th Gen CPU | Powered by Intel® Core™ i5-1135G7 with Intel® Iris® Xe Graphics for fast, efficient multitasking. |
| Sleek Portable Design | Slim 19.4mm chassis and lightweight 1.4kg body for easy portability. |
| 180° Hinge | Lay-flat hinge design for comfortable viewing and collaborative use. |
| Fast Connectivity | Equipped with Wi-Fi AC + Bluetooth 5.1 for seamless networking. |
| Energy Efficient | Long 420-minute battery life with smart power management. |
Warranty Information
| Motherboard | 1 Year |
| Keyboard | 1 Year |
| Battery | 1 Year |
| AC Cord & Adapter | 1 Year |
| Display Panel | 2 Years |
| Hard Disk, SSD & RAM | 2 Years |
| Other Parts | 2 Years |
