Technical Specifications
Main Feature
| Capacity | 650VA / 390W |
| Display Type | LCD Display |
| Frequency (Battery Mode) | 50Hz or 60Hz +/- 1Hz |
| Noise Level | <40 dB |
Battery Features
| Battery Type | 12V/7AH x 1pc |
| Voltage | 12VDC |
| Recharge Time | 4-6 Hours (90% Recovery) |
| Battery Management | Advanced Battery Management |
Input Features
| Voltage Range | 162-290Vac |
| Frequency | 50Hz or 60Hz (Auto-Sensing) |
Output Features
| Voltage Range | 220/230/240Vac +/- 10% |
| Waveform | Simulated Sinewave |
| Transfer Time | 2-6ms (Typical) |
Protection & Alarms
| Safety Protections | Overload, Discharge, Over Charge, Short Circuit |
| Voltage Protections | Over/Under Voltage, Over Heating |
| Audible Alarms | Battery Mode, Low Battery, Overload, Fault |
Physical Specs
| Dimensions | 297 x 101 x 142mm |
Warranty Info
| Service Warranty | 1 Year (Spare Parts Included) |
| Battery Warranty | 6 Months |
