Technical Specifications
Model Information
| Model | TTP-384MT |
| MPN | 99-135A001-00LF |
| Printer Type | Barcode Label Printer |
Printing Performance
| Print Resolution | 300 DPI |
| Print Speed | Up to 102 mm/sec |
| Maximum Label Length | 25.4 – 5,080 mm |
Media Handling
| Supported Paper Types | Continuous, die-cut, fan-fold, tag, notched, black mark, perforated (outside wound) |
| Paper Thickness | 0.06 – 0.254 mm |
| Tape Size | 101 mm |
| Maximum Tape Width | 241 mm |
Hardware & System
| Memory | 256 MB SDRAM |
| Storage | 512 MB Flash |
| Display | 4.3 Inch Touch LCD |
Connectivity
| Interface | USB, LAN, Serial |
Physical Specifications
| Color | Black & Gray |
| Dimensions | 440 × 336 × 514 mm |
| Weight | 23.7 kg |
Ribbon Support
| Ribbon Length | 600 m |
| Ribbon Core | 1 Inch Core (Ink Coated Outside) |
| Ribbon Width | 110 – 254 mm |
| Max Ribbon OD | 90 mm |
Warranty Information
| Warranty | 1 Year Service (Print Head Excluded) |
