Technical Specifications
Camera & Imaging
| Image Sensor | 1/3″ CMOS |
| Effective Pixels | 2MP |
| Scanning System | Progressive |
| Minimum Illumination | Color: 0.04 Lux (F2.2, AGC ON); B/W: 0 Lux with IR |
Lens & View
| Lens Type | Fixed |
| Focal Length | 4mm |
| Aperture | F2.2 |
| Angle of View | 76° (H), 41.2° (V), 87° (D) |
DORI Distance
| Detect / Observe | 57.1 m / 22.6 m |
| Recognize / Identify | 11.4 m / 5.7 m |
Video & Audio
| Video Compression | S+265, H.265, H.264B/M/H |
| Video Bitrate | 32 kbps – 4 Mbps |
| Audio Compression | G.711A, G.711U |
| Audio Sampling Rate | 8 kHz |
Power & Environment
| Power Supply | PoE 802.3af |
| Max Power Consumption | 6 W |
| Operating Temperature | -30°C to 60°C |
| Ingress Protection | IP67 |
Physical
| Dimensions | 164 × 73 × 73 mm |
| Weight | 0.3 kg |
| Warranty | 1 Year |
