Technical Specifications
General Information
| Brand | Sewoo |
| Model | LK-B24 |
| Product Type | Barcode Label Printer |
| Country of Origin | South Korea |
| Assembly | China |
Printing Performance
| Printing Method | Thermal Transfer & Direct Thermal |
| Resolution | 203 dpi |
| Maximum Print Speed | 127 mm/sec |
| Maximum Print Width | 104 mm |
| Maximum Print Length | 1000 mm |
Media Handling
| Supported Media Types | Label Roll, Fanfold |
| Paper Thickness | 0.06 – 0.18 mm |
| Maximum Media Width | 114 mm |
| Maximum Label Length | 1000 mm |
| Paper Sensors | Label Gap, Black Mark, Ribbon Encoder |
Barcode & Font Support
| 1D Barcodes | Code39, CODE128, Codabar, Interleaved 2 of 5, UPC-A, UPC-E, EAN-8, EAN-13, Postnet, MSI |
| 2D Barcodes | QR Code, DataMatrix, PDF417, MaxiCode, MicroPDF417, AZTEC |
| Font Support | EPL Bitmap Fonts, ZPL Bitmap & Scalable Fonts |
Connectivity & Interface
| Interface | USB, LAN, Serial |
Physical & Environment
| Housing Color | Black |
| Operating Temperature | 0°C – 40°C |
| Operating Humidity | 10% – 90% |
| Storage Temperature | -20°C – 60°C |
| Storage Humidity | 10% – 90% |
Warranty Information
| Warranty | 1 Year (Without Adapter) |
