Technical Specifications
General Information
| Product Type | Internal SSD |
| Interface | PCIe Gen 4.0 x4, NVMe 2.0 |
| Form Factor | M.2 (2280) |
| Controller | Samsung In-house Controller |
| Dimensions | 3.15 × 0.87 × 0.09 inches |
| Weight | Max 0.02 lb |
Storage & Memory
| Capacity | 1TB (1,000GB) |
| NAND Type | Samsung V-NAND 3-bit MLC |
| Cache Memory | 1GB Low Power DDR4 SDRAM |
Performance
| Sequential Read | Up to 7,450 MB/s |
| Sequential Write | Up to 6,900 MB/s |
| Random Read (QD32) | Up to 1,200,000 IOPS |
| Random Write (QD32) | Up to 1,550,000 IOPS |
| Random Read (QD1) | Up to 22,000 IOPS |
| Random Write (QD1) | Up to 80,000 IOPS |
Power & Efficiency
| Average Power | 5.4 W |
| Max Power (Burst) | 7.8 W |
| Idle Power | Max 50 mW |
| Voltage | 3.3 V ± 5% |
Features & Security
| TRIM Support | Supported |
| S.M.A.R.T Support | Supported |
| Garbage Collection | Auto Algorithm |
| Encryption | AES 256-bit, TCG/Opal IEEE1667 |
| Device Sleep Mode | Supported |
Reliability & Environment
| MTBF | 1.5 Million Hours |
| Operating Temperature | 0°C to 70°C |
| Shock Resistance | 1,500 G & 0.5 ms |
Software Support
| Management Software | Samsung Magician Software |
Warranty
| Warranty | 3 Years |
