Technical Specifications
Video Memory Specifications
| Memory Type | GDDR6 |
| Memory Size | 16GB |
| Memory Interface | 128-bit |
Power and Physical Specifications
| Power Connector | 1 × 8-pin PCI Express |
| Typical Board Power (TBP) | ~200–230W |
| Dimensions | 310 × 100 × 40 mm |
| Dimensions (with bracket) | 330 × 120 × 40 mm |
Clock Specifications
| Game Clock (OC Mode) | Up to 2740 MHz |
| Boost Clock (OC Mode) | Up to 3310 MHz |
| Game Clock (Silent Mode) | Up to 2620 MHz |
| Boost Clock (Silent Mode) | Up to 3230 MHz |
Bus & Compatibility
| Bus Type | PCI Express 5.0 ×16 |
| Maximum Resolution | 7680 × 4320 |
Graphics & Performance
| Stream Processors | 2048 Units |
| Architecture | AMD RDNA 4 |
Technologies
| AMD Eyefinity | Supported |
| AMD Stream Technology | Supported |
| AMD Smart Access Memory | Supported |
| AMD FreeSync | Supported |
| AMD HYPR-RX | Supported |
| AMD Radeon Anti-Lag 2 | Supported |
Cooling & Build
| Cooling Design | Triple-Ring Fan |
| Fan Control | Intelligent Fan Control |
| Thermal Interface | Honeywell PTM7950 |
| Backplate | Reinforced Metal Backplate |
| PCB Design | Premium PCB |
| Power Module | High-Efficiency DrMOS |
Additional Features
| Dual BIOS (OC Mode) | Supported |
| Dual BIOS (Silent Mode) | Supported |
| TBP Monitoring | 12V Source Detection |
| LED Lighting | Glacier White |
Display & Interface
| DisplayPort | 2 × DisplayPort 2.1a |
| HDMI | 1 × HDMI 2.1b |
| Multi-Display Support | Up to 3 Displays |
Warranty Information
| Warranty | 2 Years |
