Technical Specifications
General Information
| Product Type | Offline / Line-Interactive UPS |
| Load Capacity | 1200W |
| Topology | Line-Interactive |
| Application | Ideal for desktop PCs, monitors, and small office equipment |
| Alarm Type | Audible beeping alarm for status alerts |
| Indicator Lights | AC Mode: Green, Battery Mode: Red, Overload: Yellow |
Electrical Specifications
| Input Voltage | 175V – 275V AC |
| Output Voltage | 220V / 230V ±10% |
| Input Frequency | 50 / 60Hz ±5% |
Battery
| Battery Type | Sealed Lead-Acid (Maintenance-free) |
| Battery Configuration | 2 × 12V 9Ah batteries |
| Total DC Bus Voltage | 24V DC |
| Backup Time | 45–50 minutes (for 1 Desktop PC + 1 Monitor) |
Input & Output Features
| Input Range | 175V – 275V AC |
| Output Range | 220V / 230V ±10% |
| Backup Time (Typical Load) | Up to 50 minutes (at partial load) |
| Transfer Time | 2–6ms |
Protection & Monitoring
| Overload Protection | Automatically triggers yellow LED and alarm sound |
| Short Circuit Protection | System auto-shutdown to prevent damage |
| Low Battery Alarm | Beeping sound during low battery condition |
Physical Specifications
| Color | Black |
| Form Factor | Compact vertical tower |
| Cooling System | Automatic internal fan |
| Operating Temperature | 0°C – 40°C |
Warranty Information
| Warranty | 1 year |
