Technical Specifications
Image Sensor
| Sensor Type | 1-Chip 1/2.5″ MOS Sensor |
| Effective Pixels | 8.29 MP |
| Image Stabilization | Optical + Digital |
Lens System
| Focal Length | 4.1 to 98.9 mm |
| 35mm Equivalent | 25 to 600 mm |
| Optical Zoom | 24× |
| Maximum Aperture | f/1.8 to f/4 |
| Optical Design | 14 Elements in 11 Groups |
| Filter Size | 62 mm |
Focus & Exposure
| Focus Type | Auto / Manual Focus |
| Gain Range | 0 to 30 dB |
| White Balance | 2000K – 15,000K |
| Shutter Speed | 1/6 to 1/8000 sec |
Display & Monitoring
| Viewfinder | 0.24″ Wide EVF |
| Viewfinder Resolution | Approx. 1,560,000 dots |
| LCD Monitor Size | 3.5″ Wide LCD |
| LCD Resolution | Approx. 2,760,000 dots |
Video Recording
| Max Video Resolution | 3840 × 2160 (4K UHD) |
| Video Codecs | H.265, MOV, MP4, AVCHD |
| Color Sampling | Up to 4:2:2 10-Bit |
| Max Bitrate | Up to 200 Mb/s |
Audio Recording
| MOV Audio | 2-Channel 24-Bit LPCM |
| MP4 Audio | 2-Channel 24-Bit AAC |
| AVCHD Audio | 2-Channel 24-Bit AC-3 |
Streaming & Networking
| Streaming Protocols | RTMP, RTP, RTSP |
| Streaming Resolution | 320 × 180 to 1920 × 1080 |
| Network Control | RJ45 IP Control |
Storage
| Memory Card Support | SDHC / SDXC |
| Professional Media | microP2 (A Series, B Series) |
Connectivity
| Video Output | HDMI, 3G-SDI (BNC) |
| USB Interface | 1 × USB Micro-B |
| Audio Inputs | 2 × XLR Mic/Line (+48V) |
| Headphone Output | 3.5 mm Stereo |
| Wireless | Wi-Fi Video & Audio Output |
Physical Information
| Dimensions | 25.7 × 15.9 × 12.9 cm |
| Weight | 1.5 kg (Body Only) |
| Operating Temperature | 0°C to 40°C |
| Operating Humidity | 10% – 80% |
Warranty
| Warranty | 03 Years Service Warranty (No Parts Warranty) |
