Technical Specifications
Storage
| Capacity | 512GB |
| Sequential Read Speed | Up to 3,100 MB/s |
| Sequential Write Speed | Up to 2,700 MB/s |
Ports
| Interface | NVMe PCIe (PCIe Gen 3.0 ×4 Compatible) |
Others
| Additional Features | TRIM, ECC, SMART, Pre-Installed Heat Spreader |
| TBW (Total Bytes Written) | 300TB (Typical for 512GB NVMe SSD) |
| MTBF (Mean Time Between Failures) | 1,500,000 hours |
| NVMe Version | NVMe 1.3 / 1.4 |
Performance (IOPS)
| 4K Random Read | Up to 150,000 IOPS |
| 4K Random Write | Up to 182,000 IOPS |
Physical Specification
| Form Factor | M.2 2280 |
| Dimension (L × W × H) | 80mm × 22mm × 2.2mm |
| Weight | 7g |
Environmental Conditions
| Operating Temperature | 0°C ~ 70°C |
| Storage Temperature | -40°C ~ 85°C |
| Humidity | 5% ~ 95% (non-condensing) |
Shock & Vibration Resistance
| Shock Resistance | 1500G, duration 0.5ms, Half Sine Wave |
| Vibration Resistance | 10–2000Hz, 1.5mm, 20G, 1 Oct/min, 30min/axis (X, Y, Z) |
Compatibility
| Supported OS | Windows, Linux, macOS |
| Application | Laptops, Desktops, and Ultrabooks |
Warranty Information
| Warranty | 5 Years |
