Technical Specifications
Key Features
| Capacity | 512GB |
| Form Factor | M.2 2280 |
| Flash Type | 3D TLC NAND |
| Interface | NVMe PCIe Gen 4.0 ×4 |
| Sequential Read Speed | Up to 5,200 MB/s |
| Sequential Write Speed | Up to 4,700 MB/s |
| TBW (Total Bytes Written) | 325TB |
Performance & Features
| Category | Details |
| Function Support | TRIM, NCQ, and S.M.A.R.T |
| Cache Type | Independent Cache |
| Heat Spreade | r Low-Profile Graphene Aluminum Heat Spreader |
| NVMe Version | NVMe 1.4 |
| ECC Support | LDPC (Low-Density Parity Check) Error Correction |
| SMART Support | Yes |
| TRIM Support | Yes |
| End-to-End Data Path | Protection Supported |
| Thermal Throttling | Supported (Dynamic Temperature Management) |
Physical Specification
| Dimension (L × W × H) | 80mm × 22mm × 2mm |
| Color | Black |
| Weight | Approx. 7g |
Environmental Conditions
| Operating Temperature | 0°C ~ 70°C |
| Storage Temperature -40°C ~ 85°C | -40°C ~ 85°C |
| Humidity | 5% ~ 95% (non-condensing) |
Shock & Vibration Resistance
| Shock Resistance 1 | 500G, duration 0.5ms, Half Sine Wave |
| Vibration Resistance | 10–2000Hz, 1.5mm, 20G, 1 Oct/min, 30min/axis (X, Y, Z) |
Compatibility
| Supported OS | Windows 10/11, macOS, Linux |
| Application | Gaming PCs, Laptops, Desktops, and Ultrabooks |
Warranty Information
| Warranty | 05 Years |
