Technical Specifications
GPU Architecture
| Architecture | NVIDIA Blackwell Architecture |
| CUDA Cores | 24,064 Parallel Processing Cores |
| Tensor Cores | 752 (5th Generation) |
| RT Cores | 188 (4th Generation) |
Performance
| Single-Precision (FP32) | 120 TFLOPS |
| Peak FP4 AI Performance | 4 PFLOPS |
| RT Core Performance | 355 TFLOPS |
Memory
| Memory Capacity | 96 GB GDDR7 with ECC |
| Memory Interface | 512-bit |
| Memory Bandwidth | 1597 GB/s |
Power & Thermal
| Power Consumption | Up to 600W (Configurable) |
| Thermal Solution | Passive, Air or Liquid-Cooled |
| Form Factor | Air: Dual-Slot FHFL / Liquid: Single-Slot FHXL |
| Power Connector | 1x PCIe CEM5 16-pin |
Connectivity
| Graphics Bus | PCI Express 5.0 x16 |
| Display Connectors | 4x DisplayPort 2.1 |
Advanced Features
| Multi-Instance GPU | Up to 4 MIGs @ 24GB |
| Video Encoders | 4x NVENC |
| Video Decoders | 4x NVDEC |
| JPEG Engines | 4x |
Security
| Confidential Computing | Supported |
| Secure Boot | Root of Trust Enabled |
Warranty
| Warranty Coverage | No Information |
