Technical Specifications
GPU Architecture
| Architecture | NVIDIA Blackwell |
| CUDA Cores | 24,064 |
| Tensor Cores | 5th Gen |
| Ray Tracing Cores | 4th Gen |
Performance
| AI TOPS | 4000 |
| Single-Precision | 125 TFLOPS |
| RT Core Performance | 380 TFLOPS |
Memory
| Capacity | 96 GB GDDR7 ECC |
| Interface | 512-bit |
| Bandwidth | 1792 GB/s |
Connectivity
| System Interface | PCIe 5.0 x16 |
| Display Connectors | 4x DisplayPort 2.1b |
| Max Displays | Up to 4x 8K |
Video Engines
| NVENC | 4x (9th Gen) |
| NVDEC | 4x (6th Gen) |
Power & Cooling
| Board Power | 600 W |
| Connector | 1x PCIe CEM5 16-pin |
| Thermal Solution | Double-flow-through |
Form Factor
| Dimensions | 5.4” H x 12” L |
| Slot | Dual slot, extended height |
APIs
| Graphics APIs | DirectX 12, Shader Model 6.6, OpenGL 4.63, Vulkan 1.33 |
| Compute APIs | CUDA 12.8, OpenCL 3.0, DirectCompute |
Warranty Information
| Warranty | No Information |
