Technical Specifications
Processor Support
| CPU Socket | LGA 1700 |
| Generation Support | Intel 12th, 13th, 14th Gen |
| Compatible CPUs | Core, Pentium Gold, Celeron |
Chipset & Form Factor
| Chipset | Intel H610 |
| Form Factor | Micro-ATX (23.6 cm x 20.2 cm) |
Memory Specifications
| Memory Type | DDR4 |
| Max Capacity | 64GB |
| Memory Slots | 2x DIMM |
| Speed Support | 3200 / 2933 / 2666 / 2133 MHz |
Expansion & Storage
| Main PCIe Slot | 1x PCIe 4.0 x16 |
| Extra PCIe Slot | 1x PCIe 3.0 x1 |
| M.2 Storage | 1x M.2 (PCIe 3.0 x4 & SATA) |
| SATA Ports | 4x SATA 6Gb/s |
I/O & Connectivity
| Video Ports | 1x HDMI 2.1, 1x DP 1.4, 1x VGA |
| USB Ports | 4x USB 3.2 Gen 1, 6x USB 2.0 |
| Networking | Intel I219V 1Gbps LAN |
| WiFi Slot | 1x M.2 E-key (Module separate) |
Audio & Power
| Audio Codec | Realtek ALC892/897 7.1-CH |
| Power Connectors | 24-pin ATX & 8-pin 12V |
Warranty
| Period | 3 Years |
