Technical Specifications
Model Information
| Dynamic Contrast Ratio (DCR) | 100,000,000:1 |
| Viewing Angle (H/V) | 178° / 178° |
| Display Colors | 1.07B (10-bit, 8-bit + FRC) |
| Surface Treatment | Anti-Glare |
| Frameless Design | Yes |
| Item | Details |
| Brand | MSI |
| Model | G253PF |
| Panel Size | 24.5″ |
| Panel Type | Rapid IPS |
| Curvature | Flat |
| Resolution | 1920 × 1080 (Full HD) |
| Aspect Ratio | 16:9 |
| Pixel Pitch | 0.2832 (H) × 0.2802 (V) mm |
| Active Display Area (mm) | 543.744 (H) × 302.616 (V) |
| Brightness (Typical) | 250 nits (SDR) |
| Contrast Ratio (Static) | 1000:1 |
Display Performance
| Feature | Specification |
| Refresh Rate | 300 Hz |
| Activated Range | 48 – 300 Hz |
| Response Time | 0.5 ms (GtG, Min.) |
| Dynamic Refresh Rate Tech | AMD FreeSync Premium |
| HDR Support | HDR Ready |
| Signal Frequency | 53.28 – 333 kHz (H) / 48 – 300 Hz (V) |
| Color Gamut (CIE 1976) | Adobe RGB 87 % / DCI-P3 90 % / sRGB 120 % |
Audio
| Specification | Details |
| Built-in Speaker | Yes |
| Speaker Output | 2 W × 2 |
| Audio Ports | 1 × Headphone-out (3.5 mm) |
Connectivity
| Port Type | Details |
| DisplayPort 1.4a | 1 × — Supports up to 300 Hz (FHD) |
| HDMI 2.0b | 2 × — Supports up to 240 Hz (FHD) |
| Headphone Jack | 1 × — Audio output |
Mechanical Design
| Feature | Specification |
| Tilt Adjustment | -5° ~ +20° |
| Swivel Adjustment | -30° ~ +30° |
| Pivot Adjustment | -90° ~ +90° |
| Height Adjustment | 0 ~ 130 mm |
| Kensington Lock | Yes |
| VESA Mount | 100 × 100 mm |
| Stand Type | Ergonomic Adjustable |
Power
| Specification | Details |
| Power Type | Internal Power Board |
| Input Voltage | 100 – 240 V AC, 50/60 Hz |
| Power Consumption (Typical) | Approx. 30 W |
| Power Saving / Off Mode | < 0.5 W / < 0.3 W |
Physical Specification
| Specification | Details |
| Dimensions (With Stand) | 557.1 × 227.9 × 511.9 mm (21.93″ × 8.97″ × 20.15″) |
| Dimensions (Without Stand) | 557.1 × 66.4 × 326.9 mm (21.93″ × 2.61″ × 12.87″) |
| Carton Dimensions | 630 × 142 × 508 mm (24.8″ × 5.59″ × 20″) |
| Weight (Net / Gross) | 5.3 kg / 7.8 kg (11.68 lbs / 17.2 lbs) |
| Color | Black |
Accessories
| Included Items | Description |
| 1 × DisplayPort Cable (1.4a) | For high-refresh connection |
| 1 × Power Cord (C13) | AC power input |
| 1 × Quick Guide | User manual |
| 4 × Stand Screws | Assembly hardware |
Warranty Information
| Warranty | 3 Years |
