Technical Specifications
General Information
| Product Category | Gadget |
| Product Sub-Category | Smart Watch |
| Brand | Mobvoi |
| Model | TicWatch Pro 5 |
| Color Options | Obsidian / Sandstone |
Design & Build
| Dimensions | 50.1 × 48.0 × 12.2 mm |
| Weight | 44.3 g |
| Case Material | Metal, 7000-series aluminum, nylon with fiberglass |
| Strap Type | Solid silicone |
| Strap Width | 24 mm (interchangeable) |
| Glass Protection | Corning Gorilla Anti-fingerprint |
Display
| Display Size | 1.43 inch |
| Resolution | 466 × 466 |
| Pixel Density | 326 ppi |
| Display Type | AMOLED + Ultra-low-power display |
| Always On Display | Yes |
Performance & OS
| Operating System | Wear OS 3 |
| Platform | Snapdragon® W5+ Gen 1 |
| RAM | 2 GB |
| Internal Storage | 32 GB |
Connectivity
| Bluetooth | Bluetooth 5.2 |
| Wi-Fi | 2.4 GHz |
| NFC | Yes (Google Pay, 13.56 MHz) |
Navigation
| GNSS | GPS, Beidou, Glonass, Galileo, QZSS |
Sensors
| Motion Sensors | Accelerometer, Gyro |
| Health Sensors | HD PPG HR, SpO₂, Skin Temperature |
| Environmental Sensors | Barometer, Compass |
| Other Sensors | Low-latency Off-body |
Audio & Haptics
| Speaker | Yes |
| Microphone | Yes |
| Vibration Motor | Yes |
Battery & Durability
| Battery Capacity | 628 mAh (typical) |
| Water Resistance | 5 ATM |
| Durability Standard | MIL-STD-810H |
Compatibility & App
| Smartphone Compatibility | Android 8.0 or newer |
| Companion App | Mobvoi Health |
Warranty
| Warranty | Manufacturer Warranty (as per PCB Store policy) |
