Technical Specifications
Camera & Video
| Image Sensor | 1 / 2.8″ 3 Megapixel CMOS |
| Effective Pixels | 3 MP |
| Compression | H.264 |
| Bit Rate | 32 Kbps – 2 Mbps |
| Frame Rate | 1 – 25 fps |
| IR Distance | Up to 10 m |
| WDR | DWDR |
| Day / Night | Auto (ICR) / Color / B & W |
| Min. Illumination | Color 0.1 Lux @ F2.0 |
| Min. Illumination (B/W) | 0.01 Lux @ F2.0 |
Lens & Field of View
| Focal Length | 3.6 mm @ F2.0 |
| Field of View | 100° / 85° / 50° |
Pan / Tilt
| Pan Range | 0° – 350° |
| Tilt Range | -15° – 45° |
Audio & Detection
| Audio Input / Output | Built-in mic / speaker |
| Alarm Trigger | Intelligent motion / sound detection |
Network & Protocol
| Wireless | 2.4 GHz & 5 GHz Wi-Fi (802.11 b/g/n) |
| Communication Protocol | HTTP, DHCP, DNS, TCP/IP, RTSP |
| Interface Protocol | Private |
| Security | AES128 |
Storage & Compatibility
| Storage Options | TF card (up to 256 GB), Cloud, NVR |
| Mobile OS Support | iOS 9 or later, Android 5 or later |
Power & Physical
| Power Supply | DC 5 V / 1 A |
| Power Consumption | Max. 4.5 W |
| Dimension | φ82 × 106 mm |
| Weight | 188 g |
| LAN Port | N/A |
Warranty
| Warranty | 2 Years |
