Technical Specifications
Camera & Imaging
| Sensor | 1/2.5 inch CMOS |
| Effective Pixels | 8.51 Megapixels |
| Minimum Illumination | 0.5 Lux (F1.8, AGC ON) |
| White Balance | Auto, Indoor, Outdoor, One Push, Manual |
| Backlight Compensation | Supported |
| Noise Reduction | 2D and 3D Digital Noise Reduction |
Video Resolution
| Ultra HD | 4K@30fps, 25fps, 29.97fps |
| Full HD | 1080P@60fps, 50fps, 30fps, 25fps, 59.94fps, 29.97fps |
| Interlaced | 1080I@60fps, 50fps, 59.94fps |
| HD | 720P@60fps, 59.94fps, 50fps |
Lens & Viewing Angle
| Optical Zoom | 12x |
| Digital Zoom | 5x |
| Horizontal View | 71° |
| Vertical View | 42.7° |
| Diagonal View | 82.8° |
PTZ & Preset Control
| Horizontal Rotation | ±170° |
| Vertical Rotation | ±30° |
| Pan Speed | 1.6°/s to 76°/s |
| Tilt Speed | 0.5°/s to 15°/s |
| Preset Positions | 255 |
| Preset Accuracy | 0.1° |
Video & Audio Encoding
| Video Compression | H.264, H.265, MJPEG |
| Video Format | H.264 AVC/SVC up to 2160P@30fps |
| Video Streams | First Stream, Second Stream |
| Audio Compression | AAC, G711A |
| Audio Bitrate | 96 Kbps, 128 Kbps |
| Video Bitrate | 48–128 Kbps |
| Bitrate Control | Variable, Fixed |
Network & Protocols
| Supported Protocols | TCP/IP, HTTP, RTSP, RTMP, ONVIF, DHCP, Multicast |
| Primary Stream | 3840×2160, 1920×1080, 1280×720, 1024×576 |
| Sub Stream | 720×480, 640×480, 480×320, 320×240 |
Control Interfaces
| Remote Control | IR Remote |
| Serial Control | RS232, RS485 |
| Control Protocols | VISCA, Pelco-D, Pelco-P |
| Network Control | VISCA over IP, ONVIF |
| Web Control | Browser, HTTP CGI |
| PTZ via USB | Supported |
USB & System Support
| USB Protocol | UVC 1.1–1.5 |
| USB Encoding | H.264, MJPEG |
| USB Video | Up to 2160p@30fps |
| USB Audio | Supported |
| Operating Systems | Windows 7/8/10/11, macOS, Linux, Android |
Physical & Interface
| Dimensions | 238 × 167 × 149 mm |
| Weight | 1.35 kg |
| Video Outputs | HDMI, USB 2.0, 3G-SDI |
| Audio Output | 3.5 mm Jack |
| Network Port | RJ45 |
| Power Interface | Power Jack |
Environmental & Warranty
| Operating Temperature | -10 °C to 40 °C |
| Storage Temperature | -40 °C to 60 °C |
| Warranty | 2 Years (Box Required) |
