Technical Specifications
General
| Model No. | SF-2800F14HP |
| Wattage | 2800W |
| Efficiency | Cybenetics Titanium 230V (≥93%–<95%) |
| Design Guide | ATX 12V v2.32, EPS 12V v2.92, ATX 3.1 |
| AC Input | 200–240V, 15A, 50/60Hz |
| Input Type | Single Voltage 230V (Active PFC) |
Cooling
| Fan Size | 140mm |
| Fan Type | Double Ball Bearing |
| Thermal Control | Intelligent Fan Control |
Cables
| 20+4 Pin | 1 cable (600mm) |
| 4+4 Pin CPU | 2 cables (750mm) |
| PCI-E 6+2 Pin | 6 cables (750mm) |
| 12+4 Pin (12V-2x6) VGA | 4 cables (700mm) |
| SATA | 4 cables (550+110+110+110mm) |
| Molex | 1 cable (550+100+100+100mm) |
Build & Components
| Capacitors | Japanese Capacitors |
| Circuit Design | Bridgeless PFC, Full-Bridge LLC Resonant |
| Connector Innovation | Patented 20+4 Pin Connector (Taiwan M563575; China 7566010) |
| Transformer | High Efficiency Transformer (Patented) |
| Materials | RoHS/WEEE Compliant |
Compatibility
| CPU Support | Intel/AMD Multi-Core |
| GPU Support | Up to NVIDIA 50 Series, Radeon 9000 Series |
| Multi-GPU Support | NVIDIA SLI, AMD CrossFireX |
| Motherboard Support | ATX/BTX |
Warranty Information
| Warranty | 10 years |
