Technical Specifications
General Information
| Form Factor | M.2 2280 |
| Capacity | 256GB |
| NAND Flash Type | 3D NAND |
| Controller | Kimtigo Custom Controller |
| Brand | Kimtigo |
| Model | TP3000 |
| Type | NVMe M.2 Solid State Drive |
| Interface | PCIe 3.0 x4 |
Performance
| Sequential Read Speed (MB/s) | Up to 2000 MB/s |
| Sequential Write Speed (MB/s) | Up to 1300 MB/s |
| Max Random Read Speed (IOPS) | Up to 202K IOPS |
| Max Random Write Speed (IOPS) | Up to 280K IOPS |
Reliability & Endurance
| MTBF | Over 1,000,000 Hours |
| Data Retention | 10 Years (at 25°C typical) |
Physical Specifications
| Dimensions | 80 × 22 × 2.4 mm |
| Weight | Less than 10 g |
| Form | Single-Sided PCB |
Environmental
| Operating Temperature | 0°C to 70°C |
| Storage Temperature | -40°C to 85°C |
| Vibration Resistance | 3.1 GRMS (2–500Hz) |
| Shock Resistance | 100 G / 6 ms |
Certifications
| Compliance | CE, FCC, RoHS, cTUV Certified |
Warranty information
| Warranty | 03 Years |
