Technical Specifications
Specification
| Capacity & Power | 1KVA |
| Load Capacity | 700 W |
| Power Factor | 0.9 (1.0 optional) |
Input Characteristics
| Input Voltage Range | 120–295 VAC |
| Input Frequency | 50/60 Hz ±10% (auto sensing) |
| Input Power Factor | ≥0.99 |
Output Characteristics
| Output Voltage | 208 / 220 / 230 / 240 VAC ±1% (selectable) |
| Transfer Time | 0 ms |
| Backup Time | 10–15 minutes @ actual load |
Battery System
| Battery Type | 12V 9Ah |
| Battery Configuration | 2 pcs (24VDC) |
| Charger Current | Max. 1A |
Display & Interface
| Display Type | LCD |
| Communication Ports | RS232, USB slot, EPO |
| Optional Interface | SNMP, RS485 + dry contact |
Protection & Alarm
| Protection Features | Low battery, overload, short-circuit, over-temperature |
| Alarm Indicators | Low battery, AC abnormal, UPS fault |
Environmental
| Operating Temperature | -5°C to 40°C |
| Relative Humidity | 0–95%, non-condensing |
Physical Specification
| Dimensions | 190 × 400 × 330 mm |
| Weight | 22.9 kg |
| Warranty | 1 year (UPS), 6 months (Battery) |
