Technical Specifications
General Specifications
| Model | NF-2 ARGB Black |
| Dimensions | 146mm*65mm*28.1mm |
| Fan Bearing | 50mm*50mm*20mm |
| Fan Speed | 600-3600RPM (±10%) |
| Noise Level | 22.4dB(A) (MAX) |
| MTTF | ≥20000h @25℃ |
| Power Consumption | Fan 0.72W(MAX), LED 1.2W |
| Rated Voltage | Fan 12V, LED 5V |
| Rated Current | Fan 0.06A, LED 0.24A |
Fan Performance
| Fan Speed | 600-3600RPM (±10%) |
| Airflow | (1.30-9.11)*2 CFM (MAX) |
| Air Pressure | 0.17-1.6mmH2O |
| Noise Level | 22.4dB(A) (MAX) |
| Fan MTTF | ≥20000h @25℃ |
Connector and Compatibility
| FAN Connector | 4Pin PWM |
| LED Connector | 3Pin ARGB |
| Compatibility | Intel, AMD |
| Sockets Compatible | LGA 1200, LGA 1151, LGA 1150, LGA775, LGA1366, LGA1155, LGA1156, LGA2011, LGA2066, FM1, FM2, AM2, AM2+, AM3+, AM4, LGA1700 |
Power Specifications
| Fan Power | 0.72W(MAX) |
| LED Power | 1.2W |
| Rated Voltage | Fan 12V, LED 5V |
| Rated Current | Fan 0.06A, LED 0.24A |
Lighting and Aesthetics
| ARGB Support | Yes |
| LED Connector | 3Pin ARGB |
Size and Form Factor
| Dimensions | 146mm*65mm*28.1mm |
| Fan Bearing Type | 50mm*50mm*20mm |
Warranty Information
| Warranty | 1 Year |
