Technical Specifications
Display Specifications
| Screen Size | 65 Inch |
| Resolution | 3840 × 2160 (4K UHD) |
| Panel Type | D-LED |
| Aspect Ratio | 16:09 |
| Brightness | 380 cd/m² |
| Contrast Ratio | 1,200:1 |
| Viewing Angle | 178° H / 178° V |
| Color Depth | 10-bit, 1.07B colors |
Touch System
| Touch Points | Android 30 / Windows 50 |
| Touch Accuracy | ±1 mm |
| Response Time | ≤ 8 ms |
| Surface Hardness | 9H |
| Glass Type | 3.2 mm Anti-Glare |
| Bonding Gap | 0.5 mm |
System & Performance
| Operating System | Android 13+ |
| CPU | Quad A73 + Quad A53 |
| Max CPU Speed | 2.2 GHz / 2.0 GHz |
| GPU | Mali G52-MP8 |
| RAM | 8 GB |
| Storage | 128 GB ROM |
Connectivity & Interfaces
| HDMI | 2× In / 1× Out |
| USB Ports | USB-C ×1, USB 3.0 ×4, USB 2.0 ×1 |
| LAN | 2× Gigabit Ethernet |
| Wireless | Wi-Fi 5 & Wi-Fi 6 |
| Audio | Mic In, Audio In/Out, SPDIF |
| Control Ports | RS232, Touch Out ×3 |
Physical & Power
| Dimensions (W×D×H) | 1511.6 × 86.1 × 909 mm |
| Net Weight | 45 kg ±1.5 kg |
| Power Input | AC 100–240V, 50/60Hz |
| Max Power Draw | 260 W (without OPS) |
| Panel Lifetime | ≥30,000 Hours |
Warranty Information
| Warranty | 1 Year |
