Technical Specifications
General Information
| Specification | Details |
| Model | UD750GM 750W (750W Gold Modular PSU) |
| PSU Type | ATX |
| Form Factor | Standard ATX |
| Total Power Output | 50 Watts |
| Efficiency (Approx.) | 90% at Typical Load |
| Certification | 80 PLUS Gold |
| Modular Type | Fully Modular |
| Fan Type | 120mm Hydraulic Bearing (HYB) Fan |
| Cooling Design | Silent operation with high-efficiency cooling |
| MTBF (Estimated) | 100,000 Hours (Typical for this class) |
Electrical & Technical Specifications
| Specification | Details |
| Input Voltage | 100 – 240 Vac (Full Range) |
| Input Frequency Range | 50 – 60 Hz |
| Input Current | 12 – 6A |
| Efficiency Rating | Up to 90% (Typical Load) |
| Power Factor Correction (PFC) | Active PFC |
| Topology | DC to DC Conversion |
| Cooling System | 120mm Hydraulic Bearing Fan |
Connectors
| Specification | Details |
| Main Power (Motherboard) | 1 × 20+4 Pin ATX/MB – 610mm |
| CPU (EPS) | 2 × 4+4 Pin – 600mm each |
| PCI-E (GPU) | 4 × 6+2 Pin – (600mm + 150mm) × 2 |
| SATA | 8 × SATA – (600mm + 150mm + 150mm + 150mm) × 2 |
| Peripheral (Molex) | 3 × 4-Pin Peripheral + 1 × 4-Pin Floppy – (500mm + 120mm + 120mm + 150mm) × 1 |
Cooling System
| Specification | Details |
| Fan Size | 120mm |
| Fan Bearing Type | Hydraulic Bearing (HYB) |
| Cooling Performance | Optimized for quiet and efficient airflow |
| Operation Noise Level | Low-noise operation under heavy load |
Physical Specifications
| Specification | Details |
| Color | Black |
| Build Quality | Solid steel chassis with premium modular cables |
| Design | Fully modular layout for easy cable management |
| Form Factor | ATX Standard |
Warranty Information
| Specification | Details |
| Warranty | 5 Years |
