Technical Specifications
General
| Product Type | CCTV Camera |
| Model | CS-CV246-A0-1C2WFR |
| Camera Type | PTZ IP Camera |
| Housing | Dome |
Image & Video
| Sensor | 2MP, 1/2.9" Progressive Scan CMOS |
| Lens | 4mm |
| Resolution | 1920 x 1080 |
| Frame Rate | Up to 15fps |
| Video Compression | H.264 |
| H.264 Profile | Main Profile |
| Digital WDR | Yes |
| 3D Noise Reduction | Yes |
Pan & Tilt
| Pan Range | 340° |
| Tilt Range | 120° |
| Vertical Rotation | Up 105°, Down 15° |
Night Vision
| Day/Night Mode | IR-Cut Filter with Auto Switch |
| IR Distance | 10 Meter |
Network & Wireless
| Signal System | Wi-Fi |
| Frequency Range | 2.4 GHz~2.4835 GHz |
| Pairing Mode | AP Pairing, Wi-Fi Pairing |
| Max Bit Rate | 2Mbps |
| Stream Support | Dual-Stream |
| Protocol | EZVIZ Cloud Proprietary Protocol |
Audio & Smart Functions
| Two-Way Talk | Yes |
| Motion Detection | Smart Alarm |
| Privacy Shutter | Yes |
| Heart Beat | Yes |
| Mirror Image | Yes |
| Password Protection | Yes |
| Watermark | Yes |
| Anti-Flicker | Yes |
Power & Physical
| Power Supply | DC 5V/1A |
| Power Consumption | Maximum 5.0W |
| Dimensions | 3.45 x 3.45 x 4.43 inch |
| Weight | 260g |
Warranty
| Warranty Info | No Warranty |
