Technical Specifications
Projection
| Projection System | 3LCD |
| Native Resolution | XGA (1024 × 768) |
| Aspect Ratio | 4:3 |
| Colour Light Output | 3,300 lumens |
| White Light Output | 3,300 lumens |
Lens & Throw
| Lens Type | Manual focus, no optical zoom |
| Focal Length | 16.70 mm |
| F-number | 1.44 |
| Throw Ratio | 1.00 – 1.35 (digital zoom) |
| Screen Size Range | 30″–350″ (Wide), 22″–259″ (Tele) |
Lamp & Light Source
| Lamp Type | 210 W UHE |
| Light Source | Lamp |
| Lamp Life | 6,000 h (Normal), 12,000 h (Eco) |
Image Adjustment
| Keystone Correction | ±30° horizontal / vertical |
Performance & Operation
| Start-up Time | Up to 6 seconds |
| Warm-up Time | 30 seconds |
| Direct Power On/Off | Yes |
| Operating Altitude | 0 – 3,048 m |
Maintenance
| Air Filter Type | High efficiency filter |
| Maintenance Cycle | 6,000 / 12,000 hours |
Warranty
| Warranty | 2 Years |
