Technical Specifications
Projection System
| Technology | 3LCD |
| Native Resolution | 1280 × 800 (WXGA) |
| Aspect Ratio | 4:3 |
| Color Processing | 10-bit |
Brightness Output
| Color Brightness | 4200 lumens |
| White Brightness | 4200 lumens |
Lens & Throw
| Lens Type | Manual focus |
| Focal Length | 18.2–29.2 mm |
| F-Number | 1.51–1.99 |
| Throw Ratio | 1.58–2.56 |
| Optical Zoom | 1.0–1.6× |
| Screen Size | 29″–280″ |
Keystone & Adjustment
| Keystone Correction | ±30° vertical / horizontal |
| Auto Keystone | Vertical only |
| Quick Corner | Supported |
Lamp & Power
| Lamp Type | 230 W UHE |
| Lamp Life (Normal) | Up to 6,500 hours |
| Lamp Life (ECO) | Up to 17,000 hours |
| Light Source | Lamp |
Environment
| Operating Altitude | 0–3,000 m |
| High Altitude Mode | Above 1,500 m |
Control Features
| Direct Power On/Off | Supported |
Warranty
| Warranty | No Warranty |
