Technical Specifications
General Information
| Product Type | HDMI Video Capture Card |
| Capture Resolutions | 2160p30, 1440p60, 1080p60, 1080p30, 1080i, 720p60, 576p, 480p |
| Input Interface | HDMI (Unencrypted) |
| Output Interface | HDMI (Lag-Free Passthrough) |
| Dimensions (L × W × H) | 112 × 72 × 18 mm (4.4 × 2.8 × 0.7 in) |
Performance & Compatibility
| Maximum Capture Resolution | 1080p60 (Full HD HDR10, 10-bit) |
| Maximum Passthrough Resolution | 4K60 HDR10 (10-bit), 1440p120, 1080p240 |
| Supported Video Standards | HDMI 2.0 / HDCP 2.2 (Unencrypted Source Only) |
System Requirements
| Operating Systems | Windows 10 or Later, macOS (HDR Capture on Windows Only) |
| Processor (CPU) | Intel Core i5 6th Gen or AMD Ryzen 5 and Above |
| Graphics (GPU) | NVIDIA GTX 10-Series or Higher |
Warranty Information
| Duration | 2 Years |
