Technical Specifications
Power Specifications
| Capacity | 3000VA / 2700W |
| Power Factor | 0.9 |
| Technology | Online Double Conversion (VFI-SS-111) |
Input Parameters
| Nominal Voltage | 220 / 230 / 240 VAC |
| Voltage Range | 160 ~ 300 VAC |
| Frequency Range | 45-55Hz / 54-66Hz (Auto) |
Output Parameters
| Output Voltage | 220 / 230 / 240 VAC |
| Voltage Regulation | ±1% |
| Frequency (Battery) | 50 / 60 ± 0.2Hz |
| Distortion (THDi) | <5% |
Battery Details
| Battery Voltage | 72VDC |
| Battery Inclusion | Not Included |
| Efficiency (Normal) | 96% |
| Efficiency (ECO) | >99% |
Connectivity & Ports
| Interface Ports | RS 232, USB, Relay, RPO |
| Expansion Slot | 1 x SNMP / Relay Card Slot |
| Input Terminal | 1 x IEC C20 (16A) |
| Output Terminals | 8 x IEC C13 (10A) + 1 x IEC C19 (16A) |
Physical Attributes
| Dimensions | 318 x 192 x 428 mm |
| Operating Temp | 0-40° C |
| Operating Humidity | 20~90% (Non-condensing) |
Safety & Warranty
| Certifications | CE |
| Warranty | 01 Year |
