Technical Specifications
Display Panel
| Active Screen Size | 86 in. |
| Resolution | 4K UHD (3,840 x 2,160) |
| Refreshing Frequency | 60Hz |
| Brightness | 450 nits |
| Viewing Angle | Hor. 178°, Ver. 178° |
| Glass Type | 9H Tempered 3.2 mm Anti-Glare |
| Back Light Life | 50,000 hours |
System Hardware
| Operating System | Android 13.0 |
| CPU | Arm Cortex-A73 x 4 + A53 x 4 |
| GPU | G52 MP8 |
| System Memory | 8GB |
| Internal Storage | 32GB |
Touch & Software
| Number of Touch | Up to 40 Point Multi-touch |
| Response Time | 8ms |
| Built-in Software | EZ Write 6.0, InstaShare 2 |
| Device Management | AMS, DMS, X-Sign Broadcast |
Audio & Camera
| Camera | 4K, AI Auto Framing, Voice Tracking |
| Built-in Microphone | X8 Noise and Echo Cancellation |
| Sound Channel | 20W x 2 Speakers |
Connectivity
| Wi-Fi/Bluetooth | Wi-Fi 6, Bluetooth 5.2 |
| HDMI Input | 3× HDMI 2.0 |
| USB Type-C | 2x (supports 65W charging & data) |
| Other Inputs | VGA x1, DP 1.2 x1, RJ45 x1 |
Physical & Power
| Power Consumption | 169.4 W (Typical) |
| Power Requirements | 100 -240 VAC 50/60Hz |
| Warranty | 3 years Full Warranty |
