Technical Specifications
General Information
| Brand | BenQ |
| Model | MX560 |
| Product Type | Business Projector |
| Color | White |
Projection Features
| Display Technology | DLP Single 0.55" XGA |
| Native Resolution | 1024 × 768 pixels |
| Supported Resolution | VGA (640 × 480) to WUXGA_RB (1920 × 1200) |
| Brightness | 4000 ANSI Lumens |
| Contrast Ratio | 20,000:1 |
| Projection Distance | 60" – 150" |
| Supported Video Formats | NTSC, PAL, SECAM, SDTV (480i/576i), EDTV (480p/576p), HDTV (720p, 1080i/p 60Hz) |
Lamp Details
| Lamp Power Saving | SmartEco Mode Up To 70% |
| Lamp Life (Normal) | 6000 Hours |
| Lamp Life (Economic) | 10000 Hours |
| Lamp Life (SmartEco) | 10000 Hours |
| Lamp Life (LampSave) | 15000 Hours |
Audio
| Built-in Speakers | 10W × 1 |
Connectivity
| HDMI | HDMI-1 ×1, HDMI-2 ×1 |
| PC Input | D-Sub 15-pin ×1 |
| Monitor Out | D-Sub 15-pin (Female) ×1 |
| Audio In | Mini Jack ×1 |
| Audio Out | Mini Jack ×1 |
| RS-232 | D-Sub 9-pin (Male) ×1 |
| USB Type-A | ×1 (1.5A Power) |
| USB Mini-B | ×1 |
| IR Receiver | Front + Top ×2 |
| S-Video | ×1 |
| Composite Video | RCA ×1 |
Power Information
| Power Consumption | Max 280W / Normal 260W / Eco 215W |
| Standby Power | < 0.5W |
| Power Supply | 100–240V AC |
Physical Details
| Dimensions | 296 × 120 × 221 mm |
| Weight | 2.3 kg ± 200 g |
Warranty Information
| Warranty | 1 Year Parts & Service Warranty / Lamp: 12 Months or 1000 Hours |
