Technical Specifications
General Information
| Product Category | UPS |
| Product Sub-Category | UPS IPS & Power Solutions |
| Brand | Aplus |
Power & Capacity
| Capacity | 650VA / 325W |
| Load Capacity | 325W |
Input Features
| Input Voltage | 220V / 230V / 240Vac |
| Input Frequency | 50Hz or 60Hz Auto-Sensing |
| Voltage Range | -30% to +25% |
Output Features
| Output Voltage | 220V / 230V / 240Vac ±10% |
| Output Frequency | 50Hz or 60Hz ±1Hz |
| Waveform Type | Simulated Sinewave |
| Transfer Time | < 6ms Typical |
Battery Details
| Battery Voltage | 12V DC |
| Battery Type | 12V/7AH x 1 |
| Recharge Time | 5 hours to 90% |
| Battery Management | Advanced Battery Management |
| Safety Protection | Overcharge and Over Discharge |
Indicators & Alarm
| LED Indicators | Green Yellow Red |
| Alarm Battery Mode | Two short tones every 8 seconds |
| Alarm Low Battery | Four short tones every second |
| Alarm Overload | Continuous beeping |
| Alarm Fault | Continuous sound |
Physical Specification
| Dimensions | 315.5 x 100 x 141 mm |
| Noise Level | < 40 dB at 1 meter |
Warranty
| Manufacture Warranty | 02 Years |
